Description
The Noctua NH-L12S cooler, in its beige and nickel finish, combines a 12 cm fan with an aluminium radiator for cooling AMD A, Intel Celeron, and Pentium processors. Its rotation ranges between 450 and 1850 RPM, generating an airflow of up to 94.2 m³/h with a maximum pressure of 1.53 mmH2O and a maximum noise level of 23.9 dB; with the LNA adapter, it drops to 1400 RPM, 70.8 m³/h, and 16.8 dB. It includes PWM control and an SSO bearing that ensures an average lifespan of 150,000 hours. Designed for processor mounting, it offers quiet and stable performance for compact systems.
Specifications
Performance
- Maximum air pressure: 1.53 mmH2O
- Pulse-width modulation (PWM) support: Yes
- Bearing type: Self-Stabilising Oil-pressure Bearing (SSO)
- Mean time between failures (MTBF): 150000 h
- Suitable location: Processor
- Type: Cooler
- Fan diameter: 12 cm
- Supported processor sockets: Intel LGA1851, LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA
- Compatible processor series: AMD A, Intel® Celeron®, Intel® Pentium®
- Rotational speed (min): 450 RPM
- Rotational speed (max): 1850 RPM
- Rotational speed with LNA (max): 1400 RPM
- Noise level (high speed): 23.9 dB
- Noise level with LNA (max): 16.8 dB
- Airflow: 94.2 m³/h
- Airflow with LNA (max): 70.8 m³/h
Design
- Product colour: Beige, Nickel
- Material: Aluminium, Copper, Nickel
- Number of fans: 1 fan(s)
- Fins material: Aluminium
- Fan connector: 4-pin
Power
- Power supply: 1.56 W
- Voltage: 12 V
Weight & dimensions
- Width: 128 mm
- Depth: 87 mm
- Height: 146 mm
- Weight: 520 g
- Fan dimensions (W x D x H): 120 x 15 x 120 mm
- Heatsink weight: 390 g
- Package width: 142 mm
- Package depth: 146 mm
- Package height: 185 mm
- Package weight: 1.18 kg
Packaging content
- Low-noise adaptor (LNA): Yes
Other features
- Heatsink dimensions (W x D x H): 128 x 70 x 146 mm
Logistics data
- Harmonized System (HS) code: 84733080
- Master (outer) case width: 308 mm
- Master (outer) case length: 330 mm
- Master (outer) case height: 400 mm
- Master (outer) case gross weight: 10.2 kg
- Products per master (outer) case: 8 pc(s)
