Description
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- Gigabit Ethernet (copper) ports quantity: 7
- SFP+ module slots quantity: 1
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 8
- 10G support: Yes
Data transmission
- Switching capacity: 160 Gbit/s
- MAC address table: 2000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9000
Design
- Rack mounting: Yes
- Product colour: Grey, Silver
- LED indicators: Yes
- Safety: CE: CB 60950-1, LVD 60950-1, AUS/NZ: AS/NZS 60950-1, USA: UL 60950-1, SNE VA, BSMI
Performance
- Mean time between failures (MTBF): 1145157 h
Power
- Power source: AC
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 1.5 A
- Power consumption (typical): 21.31 W
- Power consumption (max): 39 W
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 3000 m
- Heat dissipation: 147.86 BTU/h
Weight & dimensions
- Width: 328 mm
- Depth: 169 mm
- Height: 43.2 mm
- Weight: 1.49 kg
Certificates
- Certification: 47 CFR FCC, ICES-003:2016 Issue 6, ANSI C63.4:2014, EN 55032:2012+AC2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS
Logistics data
- Harmonized System (HS) code: 85176990
