Description
The Mercusys MP500 kit includes two white PowerLine adapters that let you extend your home network using the electrical wiring, with no need for complex setups thanks to its plug-and-play operation. With a maximum transfer speed of 1000 Mbit/s and a Gigabit Ethernet port on each unit, you get a stable, fast wired connection in any room with a power socket, with an operating range of up to 300 metres between devices. HomePlug AV2 technology and OFDM modulation optimise data transmission over the electrical installation, while the encryption button and 128-bit AES encryption protect your network traffic from unauthorised access.
Specifications
Performance
- Maximum data transfer rate: 1000 Mbit/s
- Ethernet LAN: Yes
- Ethernet LAN interface type: Gigabit Ethernet
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Ethernet LAN (RJ-45) ports: 1
- Wi-Fi: No
- Top Wi-Fi standard: Wi-Fi 4 (802.11n)
- Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
- Built-in power socket: No
- PowerLine standard: HomePlug AV2
- Modulation: OFDM
- Security algorithms: 128-bit AES
- Maximum operating distance: 300 m
- Encryption button: Yes
- Plug and Play: Yes
Power
- Power consumption (typical): 2.35 W
- Power consumption (standby): 0.64 W
- AC input voltage: 220 V
- AC input frequency: 50 Hz
Design
- Antenna type: Internal
- LED indicators: Power
- Product colour: White
- Certification: CE
System requirements
- Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows 8.1
- Linux operating systems supported: Yes
- Mac compatibility: Yes
- Mac operating systems supported: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): 5 - 90 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 101 mm
- Depth: 60 mm
- Height: 36 mm
Packaging content
- Quantity per pack: 2 pc(s)
- Quick installation guide: Yes
- Manual: Yes
- Cables included: LAN (RJ-45)
Logistics data
- Harmonized System (HS) code: 85171800
