Description
The Lindy 38236 is an HDMI video splitter that distributes one signal between four screens thanks to its four HDMI outputs. It supports HDMI 2.0 and reaches a maximum resolution of 3840 x 2160 pixels with a refresh rate of 60 Hz, compatible with 4K Ultra HD content. It features HDCP protection and LED indicators that show the operating status. Its metal housing, in black, measures 163 x 16 x 63 mm (width x height x depth) and weighs 373 g. It has five video ports in total, with a 5 V and 1 A DC input plug for its power supply. It has CE, FCC, REACH and California Proposition 65 certification. Connect several screens to the same source without loss of image quality.
Specifications
Ports & interfaces
- DC-in jack: Yes
- Video port type: HDMI
- Video out: 4x HDMI
- HDMI version: 2.0
- Video ports quantity: 5
Features
- Product colour: Black
- Housing material: Metal
- Maximum resolution: 3840 x 2160 pixels
- HD type: 4K Ultra HD
- Maximum refresh rate: 60 Hz
- HDCP: Yes
- LED indicators: Yes
- Certification: CE, FCC, REACH, California Proposition 65
Power
- AC input voltage: 5 V
- Input current: 1 A
Weight & dimensions
- Width: 163 mm
- Depth: 63 mm
- Height: 16 mm
- Weight: 373 g
Packaging data
- Package width: 248 mm
- Package depth: 55 mm
- Package height: 183 mm
- Package weight: 526 g
- Package type: Box
Packaging content
- Manual: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 90%
Technical details
- Compliance certificates: RoHS
Logistics data
- Harmonized System (HS) code: 85176990
