KTI Networks KC-300D network media converter 100 Mbit/s 1310 nm Multi-mode
More info
Brand: KTI NETWORKS
58.80 €
48.60 €
without VAT
Stock available: 7 units.
Get it
on the
September 1
/
September 2
SKU:
78835
PRC:
155891
EAN:
8716065190052
PN:
KC-300D-T
Description
KTI Networks KC-300D network media converter operating at 100 Mbit/s with a 1310 nm wavelength and multi-mode fibre, designed for links up to 2000 metres. It connects the 100Base-TX interface via an RJ-45 Ethernet port to the ST-type fibre optic connector, using 50/125 µm cables. It complies with IEEE 802.3 and 802.3u standards, supports full or half duplex, and features auto MDI/MDI-X to simplify connection. Its link and status LED indicators allow easy verification of network operation.
Specifications
Network
- Maximum data transfer rate: 100 Mbit/s
- Converter input interface: 100Base-TX
- Networking standards: IEEE 802.3, IEEE 802.3u
- Auto MDI/MDI-X: Yes
- Duplex system: Full, Half
Performance
- Maximum transfer distance: 2000 m
- Wavelength: 1310 nm
- Fiber mode structure: Multi-mode
- Fiber cable diameters supported (core/cladding): 50/125 µm
- Tx power (min): -19 dBmW
- Tx power (max): -14 dBmW
- Rx power (min): -31 dBmW
- Rx power (max): -14 dBmW
Features
- Internal: No
- LED indicators: Link, Status
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
- Fiber ports quantity: 2
- Fiber optic connector: ST
- DC-in jack: Yes
Power
- Power consumption (typical): 2 W
Weight & dimensions
- Weight: 210 g
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -20 - 80 °C
- Operating relative humidity (H-H): 5 - 95%
Certificates
- Certification: FCC B, CE B
Logistics data
- Harmonized System (HS) code: 85176990
Other features
- Dimensions (WxDxH): 108 x 72.5 x 23 mm
- Full duplex: Yes
- Fiber type: MMF
