Kramer Electronics DSP-62-AEC AV matrix switcher
More info
Brand: KRAMER ELECTRONICS
768.32 €
634.98 €
without VAT
Stock available: 1 ud.
Get it
on the
September 1
/
September 2
SKU:
116236
PRC:
369231
EAN:
7291063090524
PN:
dsp-62-aec
Description
The Kramer Electronics DSP-62-AEC AV matrix switcher, with a black aluminium housing and CE and FCC certification, manages video and audio signals at resolutions up to 3840 x 2160 pixels with a bandwidth of 18 Gbit/s. It features two HDMI inputs and one HDMI output, all with HDCP 2.2 support, as well as an Ethernet RJ-45 port, a USB type B connection, an RS-232 port, and terminals for four analogue audio inputs and one output. Its design without an integrated screen is complemented by PoE power, simplifying installation in professional environments where reliable switching is required. This Kramer Electronics unit offers versatile connectivity for integrating audiovisual sources and destinations with remote control via network or RS-232.
Specifications
Features
- Product type: AV matrix switcher
- Maximum resolution: 3840 x 2160 pixels
- Bandwidth: 18 Gbit/s
- HDCP: Yes
- HDCP version: 2.2
Design
- Housing colour: Black
- Housing material: Aluminium
- Certification: CE, FCC
Display
- Built-in display: No
Ports & interfaces
- HDMI input ports quantity: 2
- HDMI output ports quantity: 1
- USB connector type: USB Type-B
- USB ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- RS-232 ports: 1
- Analog audio input terminal ports: 4
- Analog audio output terminal ports: 1
Power
- Output current: 630 mA
- Output voltage: 12 V
- Power over Ethernet (PoE): Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
Logistics data
- Harmonized System (HS) code: 85299097
Weight & dimensions
- Width: 190.5 mm
- Depth: 59.6 mm
- Height: 27.4 mm
- Weight: 200 g
- Package width: 345 mm
- Package depth: 165 mm
- Package height: 52 mm
- Package weight: 600 g
Packaging content
- Cables included: USB
