Description
The Intel Xeon w7-2475X processor in box format includes the stock heatsink and offers a base frequency of 2.6 GHz with a turbo boost of up to 4.8 GHz. It features 20 performance cores and 40 execution threads, along with a 37.5 MB Smart Cache to handle demanding workloads. Its LGA 4677 (Socket E) socket is compatible with professional platforms, and its DMI4 bus manages data transfer with the chipset. This model operates in 64-bit mode, with a base power of 225 W and a maximum turbo power of 270 W, designed for workstations requiring intensive computing. Its ARK ID 233418 reference identifies a robust unit within the Intel Xeon W family, aimed at rendering or virtualisation tasks.
Specifications
Processor
- Processor manufacturer: Intel
- Processor model: w7-2475X
- Processor base frequency: 2.6 GHz
- Processor family: Intel Xeon W
- Processor cores: 20
- Processor socket: LGA 4677 (Socket E)
- Processor threads: 40
- System bus rate: 0 GT/s
- Processor operating modes: 64-bit
- Performance cores: 20
- Processor boost frequency: 4.8 GHz
- Processor cache: 37.5 MB
- Processor cache type: Smart Cache
- Box: Yes
- Processor base power: 225 W
- Maximum turbo power: 270 W
- Stepping: S3
- Bus type: DMI4
- Processor codename: Sapphire Rapids
- Processor ARK ID: 233418
Memory
- Maximum internal memory supported by processor: 2 TB
- Memory types supported by processor: DDR4-SDRAM
- Memory channels: Quad-channel
- ECC: Yes
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Market segment: Workstation
- Use conditions: Workstation
- Maximum number of PCI Express lanes: 64
- PCI Express slots version: 5.0
- Supported instruction sets: SSE4.1, AMX, SSE4.2, AVX 2.0, AVX-512
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): G180729
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 4.8 GHz
- Intel® Turbo Boost Technology 2.0 frequency: 4.6 GHz
- Intel® Transactional Synchronization Extensions: Yes
- Intel® Total Memory Encryption: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Platform Firmware Resilience Support: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Active Management Technology (Intel® AMT): Yes
- Intel® OS Guard: Yes
- Intel Software Guard Extensions (Intel SGX): No
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- AVX-512 Fused Multiply-Add (FMA) units: 2
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Resource Director Technology (Intel® RDT): No
- Mode-based Execute Control (MBE): Yes
- Intel® Optane™ DC Persistent Memory Supported: No
- Intel® vPro™ Platform Eligibility: Yes
- Intel® One-Click Recovery: No
- Intel® Remote Platform Erase (RPE): No
- Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel vPro® Enterprise Platform Eligibility: Yes
- Intel® Threat Detection Technology (TDT): No
- Intel® Total Memory Encryption - Multi Key: No
- Intel® QuickAssist Software Acceleration: No
- Intel® QuickAssist Technology (QAT): 0 default devices
- Intel® Dynamic Load Balancer (DLB): 0 default devices
- Intel® Data Streaming Accelerator (DSA): 1 default devices
- Intel® In-memory Analytics Accelerator (IAA): 0 default devices
- Intel® Advanced Matrix Extensions (AMX): Yes
Operational conditions
- Tcase: 76 °C
- DTS Max: 94 °C
Technical details
- Launch date: Q1'23
- Status: Launched
- Supported memory types: DDR4-SDRAM
- Memory speed (max): 4800 MHz
- Package carrier: E1B
Logistics data
- Harmonized System (HS) code: 8542310001
Packaging data
- Package type: Retail box
Weight & dimensions
- Processor package size: 77.5 x 56.5 mm
Other features
- Maximum internal memory: 2 TB
