Description
Intel Core i5-12400F processor in tray format, a 12th generation model with six performance cores and twelve execution threads that runs at a base frequency of 2.5 GHz and reaches up to 4.4 GHz in turbo mode. This Alder Lake architecture chip is designed for the LGA 1700 socket and offers 18 MB of smart cache, with a base power of 65 W and memory support with a maximum bandwidth of 76.8 GB/s. Its connection is made via a DMI4 bus with eight lanes, and it operates in 64-bit mode, making it a balanced option for desktop builds that prioritise efficient performance in everyday tasks and demanding applications.
Specifications
Processor
- Processor manufacturer: Intel
- Processor generation: 12th gen Intel® Core™ i5
- Processor model: i5-12400F
- Processor family: Intel® Core™ i5
- Processor cores: 6
- Processor socket: LGA 1700
- Processor threads: 12
- Processor operating modes: 64-bit
- Performance cores: 6
- Processor boost frequency: 4.4 GHz
- Performance-core boost frequency: 4.4 GHz
- Performance-core base frequency: 2.5 GHz
- Processor cache: 18 MB
- Processor cache type: Smart Cache
- Processor base power: 65 W
- Maximum turbo power: 117 W
- Bus type: DMI4
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 76.8 GB/s
- Processor codename: Alder Lake
- Processor ARK ID: 134587
- Package type: Tray
Memory
- Maximum internal memory supported by processor: 128 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- Memory bandwidth (max): 76.8 GB/s
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: PC/Client/Tablet
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 5.0, 4.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992CN3
- Commodity Classification Automated Tracking System (CCATS): G167599
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: No
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: No
- Intel® Optane™ Memory Ready: Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® Standard Manageability (ISM): Yes
Operational conditions
- Tjunction: 100 °C
Logistics data
- Harmonized System (HS) code: 8542310001
Technical details
- Target market: Gaming
- Launch date: Q1'22
- Status: Launched
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- Maximum internal memory: 128 GB
