Description
Intel Xeon w3-2423 processor in tray format, designed for workstations and servers requiring balanced performance in professional computing tasks. This model from the Intel Xeon W family features 6 performance cores and 12 execution threads, with a base frequency of 2.1 GHz that can reach 4.2 GHz in turbo mode. It integrates 15 MB of Smart Cache, mounts on the LGA 4677 (Socket E) socket, and its codename is Sapphire Rapids. It has a base power of 120 W and a maximum turbo power of 144 W, operating in 64-bit mode with DMI4 bus type and a bus system at 0 GT/s.
Specifications
Processor
- Package type: Tray
- Processor manufacturer: Intel
- Processor model: w3-2423
- Processor base frequency: 2.1 GHz
- Processor family: Intel Xeon W
- Processor cores: 6
- Processor socket: LGA 4677 (Socket E)
- Processor threads: 12
- System bus rate: 0 GT/s
- Processor operating modes: 64-bit
- Performance cores: 6
- Processor boost frequency: 4.2 GHz
- Processor cache: 15 MB
- Processor cache type: Smart Cache
- Processor base power: 120 W
- Maximum turbo power: 144 W
- Stepping: S3
- Bus type: DMI4
- Processor codename: Sapphire Rapids
- Processor ARK ID: 233484
Memory
- Maximum internal memory supported by processor: 2 TB
- Memory types supported by processor: DDR5-SDRAM
- Memory channels: Quad-channel
- ECC: Yes
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Market segment: Workstation
- Use conditions: Workstation
- Maximum number of PCI Express lanes: 64
- PCI Express slots version: 5.0
- Supported instruction sets: SSE4.1, AMX, SSE4.2, AVX 2.0, AVX-512
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): G180729
Processor special features
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 4.2 GHz
- Intel® Turbo Boost Technology 2.0 frequency: 4 GHz
- Intel® Transactional Synchronization Extensions: Yes
- Intel® Total Memory Encryption: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Platform Firmware Resilience Support: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Active Management Technology (Intel® AMT): Yes
- Intel® OS Guard: Yes
- Intel Software Guard Extensions (Intel SGX): No
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- AVX-512 Fused Multiply-Add (FMA) units: 2
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Resource Director Technology (Intel® RDT): No
- Mode-based Execute Control (MBE): Yes
- Intel® Optane™ DC Persistent Memory Supported: No
- Intel® vPro™ Platform Eligibility: Yes
- Intel® One-Click Recovery: No
- Intel® Remote Platform Erase (RPE): No
- Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel vPro® Enterprise Platform Eligibility: Yes
- Intel® Threat Detection Technology (TDT): No
- Intel® Total Memory Encryption - Multi Key: No
- Intel® QuickAssist Software Acceleration: No
- Intel® QuickAssist Technology (QAT): 0 default devices
- Intel® Dynamic Load Balancer (DLB): 0 default devices
- Intel® Data Streaming Accelerator (DSA): 1 default devices
- Intel® In-memory Analytics Accelerator (IAA): 0 default devices
- Intel® Advanced Matrix Extensions (AMX): Yes
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
Operational conditions
- Tcase: 62 °C
- DTS Max: 74 °C
Technical details
- Launch date: Q1'23
- Status: Launched
- Memory speed (max): 4400 MHz
- Package carrier: E1B
Logistics data
- Harmonized System (HS) code: 8542310001
Weight & dimensions
- Processor package size: 77.5 x 56.5 mm
Other features
- Maximum internal memory: 2 TB
