Description
Intel Core i7-12700F processor tray format, featuring 12 cores (8 performance and 4 efficient) and 20 threads, reaching a maximum turbo frequency of 4.8 GHz on its performance cores. It includes 25 MB of Smart Cache and a base power of 65 W that can reach 180 W under turbo, with a supported memory bandwidth of 76.8 GB/s. The model without integrated graphics offers DMI4 bus compatibility and is designed for desktop systems, being this version without fan or box for integrators.
Specifications
Processor
- Processor generation: 12th gen Intel® Core™ i7
- Processor model: i7-12700F
- Processor family: Intel® Core™ i7
- Processor cores: 12
- Processor socket: LGA 1700
- Processor threads: 20
- Processor operating modes: 64-bit
- Performance cores: 8
- Efficient cores: 4
- Processor boost frequency: 4.9 GHz
- Performance-core boost frequency: 4.8 GHz
- Performance-core base frequency: 2.1 GHz
- Efficient-core boost frequency: 3.6 GHz
- Efficient-core base frequency: 1.6 GHz
- Processor cache: 25 MB
- Processor cache type: Smart Cache
- Package type: Tray
- Processor base power: 65 W
- Maximum turbo power: 180 W
- Bus type: DMI4
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 76.8 GB/s
- Processor codename: Alder Lake
- Processor ARK ID: 134592
- Processor manufacturer: Intel
Memory
- Maximum internal memory supported by processor: 128 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- Memory bandwidth (max): 76.8 GB/s
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: PC/Client/Tablet
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 5.0, 4.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992CN3
- Commodity Classification Automated Tracking System (CCATS): G167599
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 4.9 GHz
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- Intel® Optane™ Memory Ready: Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® Standard Manageability (ISM): Yes
Operational conditions
- Tjunction: 100 °C
Logistics data
- Harmonized System (HS) code: 85423119
Technical details
- Target market: Gaming, Content Creation
- Launch date: Q1'22
- Status: Launched
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- Maximum internal memory: 128 GB
