Description
Intel Core i7-14700KF processor in box format, with 20 cores (8 performance and 12 efficiency) and 28 threads, designed for desktop systems with LGA 1700 socket. Its 33 MB Smart Cache and 64-bit operating mode are complemented by base frequencies of 3.4 GHz on performance cores and 2.5 GHz on efficiency cores, reaching up to 5.5 GHz in turbo mode. The base power is 125 W, with a maximum of 253 W in turbo, and it supports a memory bandwidth of up to 89.6 GB/s, all with B0 stepping and 8 DMI lanes.
Specifications
Processor
- Processor manufacturer: Intel
- Processor generation: Intel® Core™ i7 (14th gen)
- Processor model: i7-14700KF
- Processor family: Intel® Core™ i7
- Processor cores: 20
- Processor socket: LGA 1700
- Processor threads: 28
- Processor operating modes: 64-bit
- Performance cores: 8
- Efficient cores: 12
- Processor boost frequency: 5.6 GHz
- Performance-core boost frequency: 5.5 GHz
- Performance-core base frequency: 3.4 GHz
- Efficient-core boost frequency: 4.3 GHz
- Efficient-core base frequency: 2.5 GHz
- Processor cache: 33 MB
- Processor cache type: Smart Cache
- Cooler included: No
- Processor base power: 125 W
- Maximum turbo power: 253 W
- Stepping: B0
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 89.6 GB/s
- Processor codename: Raptor Lake
- Processor ARK ID: 236789
- Package type: Box
Memory
- Maximum internal memory supported by processor: 192 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- Non-ECC: Yes
- Memory bandwidth (max): 89.6 GB/s
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: PC/Client/Tablet
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 4.0, 5.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Thermal solution specification: PCG 2020A
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 5.6 GHz
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® Standard Manageability (ISM): Yes
Operational conditions
- Tjunction: 100 °C
Logistics data
- Harmonized System (HS) code: 8542310001
Technical details
- Launch date: Q4'23
- Status: Launched
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- L2 cache: 28672 KB
- Maximum internal memory: 192 GB
