Description
Get the Intel Core i7-12700 12th-generation processor in boxed form, which includes a cooler so you can build without additional components. This 12-core model combines 8 performance cores and 4 efficiency cores, reaching a turbo frequency of 4.9 GHz and 3.6 GHz on the efficiency cores, with 20 threads for demanding tasks. Its 25 MB Smart Cache and LGA 1700 socket make it compatible with modern motherboards, while its 65 W base power keeps consumption in check. Manage up to 76.8 GB/s of memory bandwidth via the DMI4 bus, ideal for desktop systems seeking a balance between performance and versatility.
Specifications
Processor
- Processor manufacturer: Intel
- Processor generation: 12th gen Intel® Core™ i7
- Processor model: i7-12700
- Processor family: Intel® Core™ i7
- Processor cores: 12
- Processor socket: LGA 1700
- Processor threads: 20
- Processor operating modes: 64-bit
- Performance cores: 8
- Efficient cores: 4
- Processor boost frequency: 4.9 GHz
- Performance-core boost frequency: 4.8 GHz
- Performance-core base frequency: 2.1 GHz
- Efficient-core boost frequency: 3.6 GHz
- Efficient-core base frequency: 1.6 GHz
- Processor cache: 25 MB
- Processor cache type: Smart Cache
- Cooler included: Yes
- Processor base power: 65 W
- Maximum turbo power: 180 W
- Bus type: DMI4
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 76.8 GB/s
- Processor codename: Alder Lake
- Processor ARK ID: 134591
- Package type: Box
Memory
- Maximum internal memory supported by processor: 128 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- ECC: Yes
- Memory bandwidth (max): 76.8 GB/s
Graphics
- On-board graphics card: Yes
- Discrete graphics card: No
- On-board graphics card model: Intel UHD Graphics 770
- On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
- On-board graphics card base frequency: 300 MHz
- On-board graphics card dynamic frequency (max): 1500 MHz
- Number of displays supported (on-board graphics): 4
- On-board graphics card DirectX version: 12.0
- On-board graphics card OpenGL version: 4.5
- On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
- On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
- On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
- On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
- On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
- On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
- On-board graphics card ID: 0x4680
- Discrete graphics card model: Not available
- Number of execution units: 32
- Multi-Format Codec Engines: 2
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: PC/Client/Tablet, Workstation
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 5.0, 4.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992CN3
- Commodity Classification Automated Tracking System (CCATS): G167599
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® Quick Sync Video Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 4.9 GHz
- Intel® Total Memory Encryption: Yes
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® Active Management Technology (Intel® AMT): Yes
- Intel Stable Image Platform Program (SIPP): Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- Intel® Optane™ Memory Ready: Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® vPro™ Platform Eligibility: Yes
- Intel® Standard Manageability (ISM): Yes
- Intel® One-Click Recovery: Yes
- Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel vPro® Enterprise Platform Eligibility: Yes
- Intel® Threat Detection Technology (TDT): Yes
- Intel® Hardware Shield Eligibility: Yes
- Intel® Total Memory Encryption - Multi Key: Yes
- Intel vPro® Essentials Platform Eligibility: Yes
Operational conditions
- Tjunction: 100 °C
Technical details
- Target market: Gaming, Content Creation
- OpenCL version: 2.1
- Launch date: Q1'22
- Status: Launched
Logistics data
- Harmonized System (HS) code: 85423119
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- Maximum internal memory: 128 GB
- Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
