Description
Specifications
Performance
- Type: IP security camera
- Placement supported: Indoor & outdoor
- Connectivity technology: Wired
- PTZ control: Yes
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Languages support: Simplified Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portugu
Design
- Form factor: Dome
- Mounting type: Ceiling
- Product colour: White
- Housing material: Aluminium, Plastic
- International Protection (IP) code: IP66
- IK code: IK10
Camera
- Camera pan control: Yes
- Camera tilt control: Yes
- Lens viewing angle, horizontal: 106°
- Lens viewing angle, vertical: 55°
- Lens viewing angle, diagonal: 127°
- Tilt angle range: 0 - 67°
- Pan range: 0 - 350°
- White balance: ATW, AWC, Indoor, Manual, Outdoor
- Camera shutter type: Electronic
- Camera shutter speed: 2~1/12000 s
Image sensor
- Number of sensors: 1
- Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
- Sensor type: CMOS
Lens system
- Zoom capability: Yes
- Optical zoom: 3.1x
- Number of lenses: 1
- Lens diameter (wide): 3.3 mm
- Lens diameter (tele): 1.03 cm
- Maximum aperture number: 3.3
- Minimum aperture number: 1.6
- Detect distance (wide): 26.5 m
- Detect distance (tele): 70.3 m
- Observe distance (wide): 10.6 m
- Observe distance (tele): 28.1 m
- Recognize distance (wide): 5.3 m
- Recognize distance (tele): 14.1 m
- Identify distance (wide): 2.7 m
- Identify distance (tele): 7 m
Night vision
- Night vision: Yes
- Night vision distance: 30 m
- LED type: IR
- Infra-red wavelength: 850 nm
Video
- Maximum resolution: 1920 x 1080 pixels
- Total megapixels: 2 MP
- Video compression formats: H.264, H.265, M-JPEG
- Supported graphics resolutions: 1280 x 960, 1280 x 1024 (SXGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 800 x 448, 1024 x 768 (XGA), 1920 x 1080 (HD 1080), 640
- Frame rate: 30 fps
- Video streaming: Yes
- Noise reduction: Yes
- Noise reduction technology: Smart Super Noise Reduction (SSNR)
- Flip & mirror: Yes
- Privacy masking: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Back Light Compensation (BLC): Yes
Network
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Supported network protocols: IPv4, IPv6
- Wi-Fi: No
- Bluetooth: No
- Number of users: 6 user(s)
- Quality of Service (QoS) support: Yes
- Streaming method: Multicast, Unicast
- Live view: Yes
- Number of simultaneous live view channels: 3 channels
Storage
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash), SDHC
- Maximum memory card size: 32 GB
- Flash memory: 256 MB
- RAM capacity: 512 MB
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
Security
- Video motion detection: Yes
- Security algorithms: EAP-LEAP, EAP-TLS, HTTPS
- Alert notification type: E-mail
- Anti-flicker: Yes
- Mirror: Yes
- Digest authentication: Yes
Management features
- Remotely operated: Yes
Power
- Power source type: PoE
- Power consumption (max): 7 W
- Power consumption (Power over Ethernet (PoE)): 5 W
Operational conditions
- Operating temperature (T-T): -30 - 55 °C
- Storage temperature (T-T): -30 - 55 °C
- Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
- Height: 107.1 mm
- Diameter: 13.8 cm
- Weight: 550 g
Packaging content
- Number of cameras: 1
