Elo Touch Solution ET1093L 10.1'' 1280 x 800pixels Multi-touch Black touch screen monitor
Elo Touch Solution ET1093L, 25.6 cm (10.1"), 25 ms, 350 cd/m², LCD/TFT, 800:1, Projected capacitive system.
More infoBrand: ELO TOUCH SOLUTION
376.00 €Stock available: 0 units.
Unavailable
SKU:
116699
PRC:
190316
EAN:
815335025778
PN:
E321195
Description
Elo Touch Solution ET1093L 10.1" (25.6 cm) touch screen monitor with a resolution of 1280 x 800 pixels and 16:10 aspect ratio, in black. Its TFT-LCD screen with LED backlighting offers a brightness of 350 cd/m² and a typical contrast ratio of 800:1. It features projected capacitive touchscreen technology and reproduces 262144 colours with a response time of 25 ms. Viewing angles reach 170° both horizontally and vertically, and the visible screen area measures 216.96 x 135.6 mm. It supports compatible graphics resolutions such as 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA) and 1280 x 800, with digital frequencies from 30 to 60 kHz horizontally and from 50 to 75 Hz vertically. Its dimensions are 255.8 x 178.5 x 36.9 mm (width x height x depth) and it weighs 1.2 kg, making it easy to integrate into different workstations.
Specifications
Display
- Display diagonal: 25.6 cm (10.1")
- Display resolution: 1280 x 800 pixels
- Display type: TFT-LCD
- Display technology: LCD/TFT
- Digital horizontal frequency: 30 - 60 kHz
- Contrast ratio (typical): 800:1
- Response time: 25 ms
- Backlight type: LED
- Display brightness: 350 cd/m²
- Digital vertical frequency: 50 - 75 Hz
- Viewing angle, horizontal: 170°
- Display viewable area (HxV): 216.96 x 135.6 mm
- Aspect ratio: 16:10
- Supported graphics resolutions: 640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 800
- Touchscreen technology: Projected capacitive system
- Viewing angle, vertical: 170°
- Display number of colours: 262144 colours
Design
- Colour of product: Black
Performance
- Mean time between failures (MTBF): 50000 h
- Number of OSD languages: 8
- On Screen Display (OSD) languages: CHI (SIMPL), CHI (TR), German, English, Spanish, French, Italian, JPN
- Touch technology: Multi-touch
Ports & interfaces
- DisplayPorts quantity: 1
- HDMI ports quantity: 1
Ergonomics
- Wall mountable: Yes
- VESA mounting interfaces: 75 x 75 mm
- VESA mounting: Yes
Power
- Power supply type: AC/DC
- Power consumption (typical): 6.1 W
- Power consumption (PowerSave): 0.7 W
- Power consumption (off): 0.5 W
- AC input voltage: 100-240
- AC input frequency: 50/60
Operational conditions
- Operating altitude: 0 - 12192 m
- Storage relative humidity (H-H): 10 - 95%
- Operating relative humidity (H-H): 20 - 80%
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
- Width: 255.8 mm
- Height: 178.5 mm
- Depth: 36.9 mm
- Weight: 1.2 kg
Packaging data
- Package width: 336 mm
- Package depth: 175 mm
- Package height: 262 mm
- Package weight: 2.6 kg
