  • UPS topology: Line-Interactive
  • Output power capacity: 0.85 kVA
  • Output power: 425 W
  • Waveform: Sine
  • Input operation voltage (min): 165 V
  • Input operation voltage (max): 290 V
  • Input frequency: 50/60 Hz
  • Output operation voltage (max): 230 V
  • Output frequency: 50/60 Hz
  • Automatic Voltage Regulation (AVR): Yes
  • Maximum current: 5.21 A
  • Surge energy rating: 150 J
  • Response time: 4 ms
  • Heat dissipation: 27 BTU/h
  • Number of input phases: 1
  • Number of output phases: 1
  • EMI/RFI noise filtering: Yes
  • Surge protection: Yes
  • Power protection features: Over voltage, Overload
  • Audible alarm(s): Yes
  • Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm

Ports & interfaces


  • AC outlet types: Type F
  • AC outlets quantity: 4 AC outlet(s)
  • USB port: Yes
  • USB 2.0 ports quantity: 1
  • USB port type: USB Type-B
  • Ethernet LAN (RJ-45) ports: 2

Battery


  • Battery technology: Sealed Lead Acid (VRLA)
  • Battery recharge time: 6 h

Design


  • Form factor: Tower
  • Housing material: Plastic
  • Cable length: 1.2 m
  • Product colour: Black
  • LED indicators: Yes

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 50 °C
  • Operating relative humidity (H-H): 0 - 90%
  • Storage relative humidity (H-H): 0 - 90%
  • Operating altitude: 0 - 3000 m
  • Non-operating altitude: 0 - 3000 m

Certificates


  • Compliance certificates: RoHS
  • Certification: CE

Packaging content


  • Cables included: USB cable
  • Quick installation guide: Yes

Sustainability


  • Sustainability compliance: Yes

Weight & dimensions


  • Width: 84 mm
  • Depth: 280 mm
  • Height: 174 mm
  • Weight: 4.2 kg

Packaging data


  • Package width: 109 mm
  • Package depth: 315 mm
  • Package height: 229 mm
  • Package weight: 4.47 kg

Logistics data


  • Harmonized System (HS) code: 8504408590
  • Country of origin: China
