Description
The Corsair RMx Shift Series RM850x SHIFT is an 850 W ATX power supply in black with fully modular cabling and a 24-pin ATX main connector for the motherboard. It offers 90% efficiency and a combined power output of 849.6 W on the +12 V rail, with a maximum output current of 70.8 A on that same rail. It includes protection against overcurrent, overvoltage, overheat and short-circuit, and its AC input accepts 100 to 240 V with a frequency of 47 to 63 Hz. The motherboard power cable measures 61 cm and the PCI Express one measures 75 cm, facilitating internal cable management in cases with space for this Shift format.
Specifications
Power
- Total power: 850 W
- AC input voltage: 100 - 240 V
- AC input frequency: 47 - 63 Hz
- Input current: 5 - 10 A
- Combined power (+3.3V): 150 W
- Combined power (+12V): 849.6 W
- Combined power (+5V): 150 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 70.8 A
- Max output current (+5V): 20 A
- Max output current (+5Vsb): 3 A
- Efficiency: 90%
- Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit
Ports & interfaces
- Motherboard power connector: 24-pin ATX
- Motherboard power cable length: 61 cm
- Number of SATA power connectors: 12
- SATA power cable length: 455, 570, 685, 800 mm
- Peripheral (Molex) power connectors (4-pin): 8
- Peripheral (Molex) power cable length: 450, 550, 650, 750 mm
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 4
- PCI Express power connectors (16-pin): 1
- PCI Express power cable length: 75 cm
- Cabling type: Fully-Modular
Performance
- 80 PLUS certification: 80 PLUS Gold
- Purpose: PC/Server
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.0
- EPS version: 2.92
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 14 cm
- Number of fans: 1 fan(s)
Packaging content
- Cables included: AC, DC
- Cable tie(s) included: Yes
Certificates
- Compliance certificates: Low Voltage Directive (LVD), RoHS, UKCA
Weight & dimensions
- Width: 150 mm
- Depth: 160 mm
- Height: 86 mm
- Weight: 1.7 kg
Technical details
- Sustainability compliance: Yes
Other features
- EPS cable length: 65 cm
- Screws included: Yes
