Description
Axis 02164-001 IP security camera with a dome format, designed for indoor installation on ceiling or wall and finished in a black aluminium housing. It offers a resolution of 2688 x 1512 pixels, a horizontal viewing angle of 120° and a wide dynamic range of 120 dB, which, together with the infrared cut-off filter and day/night mode, facilitates surveillance in low-light conditions. Its shutter adjustable between 1/47500 and 1 s, minimum illumination of 0.01 lx and defog function allow sharp images to be captured in changing environments. The wired connection and digital PTZ extend remote control options, with support for 12 languages in its remote viewing interface.
Specifications
Performance
- Type: IP security camera
- Placement supported: Indoor
- Connectivity technology: Wired
- PTZ modes: Digital PTZ
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Infrared (IR) cut-off filter: Yes
- Remote viewing: Yes
- Number of languages: 12
- Languages support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russia
- Dynamic range: 120 dB
- Certification: EMC CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart
Design
- Form factor: Dome
- Mounting type: Ceiling/wall
- Product colour: Black
- Housing material: Aluminium
- Fog proof: Yes
Camera
- Minimum illumination: 0.01 lx
- Lens viewing angle, horizontal: 120°
- Lens viewing angle, vertical: 63°
- Camera shutter speed: 1/47500 - 1 s
Image sensor
- Number of sensors: 1
- Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
- Progressive scan: Yes
- Sensor type: CMOS
Lens system
- Zoom capability: Yes
- Optical zoom: 2.5x
- Number of lenses: 1
- Focal length range: 3.9 - 10 mm
- Auto focus: Yes
- Maximum aperture number: 1.5
- Closest focusing distance: 0.5 m
Video
- Maximum resolution: 2688 x 1512 pixels
- Total megapixels: 4 MP
- Video formats supported: H.264, H.265, M-JPEG
- Supported graphics resolutions: 160 x 90, 2688 x 1512
- Video intelligence analytic: Yes
- Video streaming: Yes
- Noise reduction: Yes
- Gain control type: Auto
- Privacy masking: Yes
- Text caption overlay: Yes
- Image stabilizer: Yes
Audio
- Audio system: 2-way
- Audio system full duplex: Yes
- Audio formats supported: ADPCM, LC-AAC, LPCM, PCM
- Built-in microphone: Yes
- Voice codecs: G.711, G.726, OPUS
- Audio detection: Yes
Network
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
- Supported network protocols: IPv4, IPv6 USGv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v
- Wi-Fi: No
- SIM card slot: No
- Quality of Service (QoS) support: Yes
- Live view: Yes
Storage
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Flash memory: 8194 MB
- Internal memory: 2048 MB
Ports & interfaces
- RS-485 ports: 2
- Microphone in: Yes
- Headphone outputs: 1
- Ethernet LAN (RJ-45) ports: 1
- RS-422 ports: 2
Security
- Password protection: Yes
- Video motion detection: Yes
- IP address filtering: Yes
- Security algorithms: EAP-TLS, FIPS 140-2, HTTPS
- HTTPS encryption: Yes
- Alert notification type: E-mail
- Mirror: Yes
Management features
- Remotely operated: Yes
- Behavior analysis: Line crossing detection
Power
- Power source type: DC, PoE
- Power consumption (typical): 4.6 W
- Power consumption (max): 7.7 W
- Power consumption (Power over Ethernet (PoE)): 5.1 W
- DC output voltage: 10, 28
Operational conditions
- Operating temperature (T-T): -20 - 60 °C
- Storage temperature (T-T): -40 - 65 °C
- Operating relative humidity (H-H): 10 - 85%
- Storage relative humidity (H-H): 5 - 95%
System requirements
- Windows operating systems supported: Yes
Weight & dimensions
- Width: 80 mm
- Depth: 214 mm
- Height: 68 mm
- Weight: 790 g
Packaging content
- Number of cameras: 1
Other features
- Doesn't contain: BFR, PVC
Logistics data
- Harmonized System (HS) code: 85258900
