Description
The ATEN switched and metered per-port PDU allows the power supply of up to 8 AC outlets to be managed from a single unit, with a built-in on/off switch and horizontal 1U rack mounting. It comes in black with dimensions of 220.4 x 44 x 432.4 mm (width x height x depth) and a weight of 3.38 kg, so it integrates easily into standard cabinets and racks. Its C20 coupler connector provides input to the unit, while the outputs combine C13 and C19 sockets to adapt to different types of equipment. It supports a nominal input and output voltage of 100 - 240 V and a frequency of 50 - 60 Hz, with a maximum current of 16 A and a load capacity of 3680 VA. It features LED indicators to show the operating status and a 3 m cable that provides sufficient margin to reach the power outlet.
Specifications
Design
- PDU types: Metered, Switched
- Rack capacity: 1U
- Mounting: Horizontal
- Product colour: Black
- On/off switch: Yes
Ports & interfaces
- AC outlets quantity: 8 AC outlet(s)
- Power plug: C20 coupler
- AC outlet types: C13 coupler, C19 coupler
Features
- LED indicators: Yes
- Cable length: 3 m
Power
- Nominal input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Maximum current: 16 A
- Nominal output voltage: 100 - 240 V
- Load capacity: 3680 VA
- Maximum power: 100 W
Certificates
- Certification: CE TUV-CB CE-LVD GOST
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
Weight & dimensions
- Width: 220.4 mm
- Depth: 432.4 mm
- Height: 44 mm
- Weight: 3.38 kg
Packaging content
- Cables included: AC
- Rack mount kit: Yes
Packaging data
- Package weight: 4.04 kg
- Package width: 116 mm
- Package depth: 499 mm
- Package height: 324 mm
Logistics data
- Master (outer) case net weight: 10.1 kg
- Master (outer) case width: 388 mm
- Master (outer) case length: 519 mm
- Master (outer) case height: 348 mm
- Master (outer) case gross weight: 13.3 kg
- Products per master (outer) case: 3 pc(s)
