ASUS Prime X299-A II Intel® X299 LGA 2066 (Socket R4) ATX

Not avaliable

ASUS Prime X299-A II Intel® X299 LGA 2066 (Socket R4) ATX. More info

Amount

Brand: ASUS

SKU: 84154 PRC: 281854 EAN: 4718017488594 PN: 90MB11F0-M0EAY0

Description

Specifications

Processor

Processor manufacturer: Intel
Processor socket: LGA 2066 (Socket R4)
Compatible processor series: Intel® Core™ X-series
Maximum number of SMP processors: 1
Supported processor sockets: LGA 2066

Memory

Supported memory types: DDR4-SDRAM
Number of memory slots: 8
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Supported memory clock speeds: 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266 MHz
Maximum internal memory: 256 GB
Unbuffered memory: Yes

Storage controllers

Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID levels: 0, 1, 5, 10

Graphics

Parallel processing technology support: 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, Quad-GPU CrossFireX, Quad-GPU SLI
On-board graphics card: No

Internal I/O

USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 8
Front panel audio connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Number of EATX power connectors: 2
CPU fan connector: Yes
Number of chassis fan connectors: 2
Number of COM connectors: 1
Thunderbolt headers: 1

Rear panel I/O ports

USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
Headphone outputs: 1
Microphone in: Yes
S/PDIF out port: Yes

Network

Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Intel® I219-V
Wi-Fi: No

Features

Motherboard chipset: Intel® X299
Audio chip: Realtek ALC S1220A
Audio output channels: 7.1 channels
Product colour: Black, Silver
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: Intel
Cooling type: Passive
Power source type: ATX
Windows operating systems supported: Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64

Expansion slots

PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 3
Number of M.2 (M) slots: 3

BIOS

BIOS type: UEFI AMI
BIOS memory size: 128 Mbit
ACPI version: 6.1
System management BIOS (SMBIOS) version: 3.1

Processor special features

Intel Extreme Memory Profile (XMP): Yes
Intel® Optane™ Memory Ready: Yes

Logistics data

Harmonized System (HS) code: 84733020

Weight & dimensions

Width: 305 mm
Depth: 244 mm

Packaging content

Drivers included: Yes

Other features

HDD size: 2.5/3.5"
Processor lithography: 14 nm
Utilities included: Yes
