Description
The APC SRTL5KRM2UI UPS is a double-conversion (on-line) uninterruptible power supply with 5 kVA output power capacity and 5000 W of power, in black and weighing 29.2 kg. Its dimensions are 432 x 86 x 701 mm (width x height x depth), so it fits into communications racks and technical cabinets. It offers ten AC outlets and a sine waveform with a total harmonic distortion of 2%, protecting critical equipment against mains outages and fluctuations. Its power factor and crest factor of 3:1 allow it to supply demanding loads with high start-up peaks. It operates with an input voltage of between 180 V and 275 V and an input frequency of 40/70 Hz, while the output is maintained at a maximum of 220 V and a frequency of 50/60 Hz. It includes emergency power off and auto-restart to restore service after an outage.
Specifications
Features
- UPS topology: Double-conversion (Online)
- Output power capacity: 5 kVA
- Output power: 5000 W
- Waveform: Sine
- Input operation voltage (min): 180 V
- Input operation voltage (max): 275 V
- Input frequency: 40/70 Hz
- Output operation voltage (max): 220 V
- Output frequency: 50/60 Hz
- Surge energy rating: 1260 J
- Heat dissipation: 931 BTU/h
- Power factor: 1
- Output power factor: 1
- Crest factor: 3:1
- Emergency Power Off (EPO): Yes
- Output voltage Total Harmonic Distortion (THD): 2%
- Noise level: 55 dB
- Auto-restart: Yes
Ports & interfaces
- AC outlet types: C13 coupler, C19 coupler
- Power plug: Hardwire
- AC outlets quantity: 10 AC outlet(s)
- USB port: Yes
- Serial interface: Yes
- Serial ports quantity: 1
Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Battery voltage: 180 V
- Typical backup time at full load: 5.25 min
- Battery life (max): 10 year(s)
- Battery recharge time: 1.5 h
- Automatic battery test: Yes
- Cold start: Yes
Design
- Form factor: Rackmount
- Rack capacity: 2U
- Product colour: Black
- Display type: LCD
- International Protection (IP) code: IP20
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -15 - 45 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 3048 m
- Non-operating altitude: 0 - 15240 m
Certificates
- Compliance certificates: CE, RoHS
Sustainability
- Sustainability compliance: Yes
- Sustainability certificates: Green Premium
Weight & dimensions
- Width: 432 mm
- Depth: 701 mm
- Height: 86 mm
- Weight: 29.2 kg
Packaging data
- Package width: 585 mm
- Package depth: 984 mm
- Package height: 392 mm
- Package weight: 38.5 kg
Other features
- Nominal output voltage: 230 V
- Nominal input voltage: 230 V
