Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black — image 2 of 8

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black — image 3 of 8

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black — image 4 of 8

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black — image 5 of 8

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black — image 6 of 8

Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black

Name: Zyxel LTE2566-M634 wireless router Dual-band (2.4 GHz / 5 GHz) 4G Black
Brand: ZYXEL
SKU: 283155
Price: 117 EUR
Availability: OutOfStock

More info

Brand: ZYXEL

117,00 €

Stock available: 0 units.

Unavailable

SKU: 114393 PRC: 283155 EAN: 4718937610945 PN: LTE2566-M634-EUZNV1F

Description

Zyxel LTE2566-M634 is a dual-band wireless router (2.4 GHz and 5 GHz) in black, designed to provide 4G connectivity as the primary internet access route. With support for a USB 3G/4G modem and a SIM card slot, it enables a stable mobile connection without requiring a fixed line. This model achieves transfer rates of up to 300 Mbit/s on the first band and 224 Mbit/s on the second, under the Wi-Fi 5 (802.11ac) standard; it also supports 3G and 4G networks with LTE-TDD and LTE-FDD standards. It includes features such as dynamic DNS, VLAN-based SSID assignment, and VPN pass-through, although it lacks Ethernet ports, so network output is exclusively via wireless or through compatible modems.

Specifications

WAN connection

Ethernet WAN: No
DSL WAN: No
SIM card slot: Yes
3G/4G USB modem compatibility: Yes

Wireless LAN features

Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max): 300 Mbit/s
WLAN data transfer rate (first band): 300 Mbit/s
WLAN data transfer rate (second band): 224 Mbit/s

Network

SSID-based VLAN assignment: Yes
VPN Passthrough: Yes
Ethernet LAN: No
Ethernet LAN interface type: Not available
Dynamic DNS (DDNS): Yes

Mobile network

Mobile network generation: 4G
3G: Yes
4G: Yes
4G standard: LTE-TDD & LTE-FDD
3G bands supported: 900, 2100 MHz

Ports & interfaces

USB port: Yes
USB 2.0 ports quantity: 1
Memory card slot(s): No

Management features

Web-based management: Yes
Reset button: Yes
WPS push button: Yes

Security

Security algorithms: WPA-PSK, WPA2-PSK
Firewall: Yes
Access Control List (ACL): Yes
MAC address filtering: Yes
IP address filtering: Yes
URL filtering: Yes
Network address translation (NAT): Yes

Protocols

DHCP server: Yes

Design

Product colour: Black
Indication light: Yes
Product type: Portable router

Certificates

Certification: UN38.3, CE, WEEE, RoHS, HSF,

Power

Power source type: Battery, DC
Output voltage: 5 V
Output current: 1.5 A
Battery technology: Lithium-Ion (Li-Ion)
Battery capacity: 3000 mAh

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%

System requirements

Browser supported: Internet Explorer, Edge, Firefox, Chrome, Safari
Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported: Ubuntu 12.04, Ubuntu 14.04
Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.7 Lion, Mac O
