Description

Specifications

Ports & interfaces


  • Connectivity technology: Wireless
  • Host interface: PCI Express
  • Interface: WLAN / Bluetooth

Network


  • Maximum data transfer rate: 2402 Mbit/s
  • Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Wi-Fi: Yes
  • Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
  • Frequency range: 2.4 - 5 GHz
  • Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
  • Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
  • WLAN data transfer rates supported: 54, 300, 574, 1733, 2402 Mbit/s
  • Modulation: 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM
  • Security algorithms: 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3
  • Bluetooth: Yes
  • Bluetooth version: 5.0

Design


  • Component for: PC
  • Product colour: Black, Red
  • Internal: Yes
  • Antenna: Yes
  • Antenna design: External
  • Transmitting power (CE): 23 dBm
  • Transmitting power (FCC): 27 dBm
  • Chipset: Intel Wi-Fi 6
  • Receiver sensitivity: 5 GHz : 11ax HT160:-56.25dBm 11ax HT80: -59dBm 11ax HT40: -62.25dBm 11ax HT20: -65dBm 11ac HT160:-62dBm 11ac HT80: -65.5dBm
  • Operating modes: Infrastructure mode

System requirements


  • Windows operating systems supported: Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%

Sustainability


  • Sustainability compliance: Yes

Weight & dimensions


  • Width: 95.2 mm
  • Depth: 120.8 mm
  • Height: 21.5 mm

Packaging data


  • Package width: 270 mm
  • Package depth: 215 mm
  • Package height: 47 mm
  • Package weight: 480 g

Packaging content


  • Mounting brackets included: Yes
  • Resource CD: Yes
  • Bluetooth header cable: Yes
  • Quick installation guide: Yes

Technical details


  • Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Logistics data


  • Harmonized System (HS) code: 85176990
