Return

Description

Specifications

Display


  • Panel type: VA
  • Display diagonal: 2.16 m (85")
  • Display technology: LCD
  • Display resolution: 3840 x 2160 pixels
  • Display brightness: 500 cd/m²
  • HD type: 4K Ultra HD
  • Touchscreen: No
  • Response time: 8 ms
  • Contrast ratio (typical): 4000:1
  • Dynamic contrast ratio marketing name: Mega Contrast
  • Viewing angle, horizontal: 178°
  • Viewing angle, vertical: 178°
  • Pixel pitch: 0.4875 x 0.4875 mm
  • Horizontal scan range: 30 - 81 kHz
  • Vertical scan range: 48 - 75 Hz
  • Haze rate: 28%
  • Pixel frequency (max): 594 MHz
  • RGB colour space: DCI-P3
  • Colour gamut: 92%

Ports & interfaces


  • HDMI ports quantity: 2
  • HDMI version: 2.0
  • HDMI input ports quantity: 2
  • DVI port: Yes
  • DisplayPorts quantity: 1
  • DisplayPorts in: 1
  • DisplayPort version: 1.2
  • USB port: Yes
  • USB ports quantity: 2
  • Ethernet LAN: Yes
  • Ethernet LAN (RJ-45) ports: 1
  • Wi-Fi: Yes
  • RS-232 interface: Yes
  • Infrared data port: Yes
  • Remote (IR) input: 1

Design


  • Product design: Digital signage flat panel
  • Placement supported: Indoor
  • Product colour: Black
  • Screen shape: Flat
  • VESA mounting: Yes
  • Panel mounting interface: 600 x 400 mm
  • Bezel width (bottom): 1.29 cm
  • Bezel width (side): 1.09 cm
  • Bezel width (top): 1.09 cm
  • Bezel colour: Charcoal Black

Performance


  • Purpose: Universal
  • HDCP: Yes
  • HDCP version: 2.2

Power


  • Power consumption (typical): 308 W
  • Power consumption (sleep): 0.5 W
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz

Computer system


  • Computer system: Yes
  • Computer system type: System on Chip (SoC)
  • Built-in processor: Yes
  • Operating system installed: Tizen 4.0

Weight & dimensions


  • Display width: 1897.8 mm
  • Display depth: 56.7 mm
  • Display height: 1080.8 mm
  • Display weight: 48.4 kg

Packaging data


  • Package width: 2090 mm
  • Package depth: 260 mm
  • Package height: 1247 mm
  • Package weight: 63.7 kg

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Operating relative humidity (H-H): 10 - 80%

Certificates


  • Certification: Class A 60950-1, 62368-1

Technical details


  • Audio out (Mini jack): 1

Other features


  • Audio input: Yes
  • Flash memory: 8000 MB
  • RS-232 input ports: 1
  • RS-232 output ports: 1
  • Video out: Yes
  • RJ-45 input ports: 1
  • Optional features: WMN8200SG
