Description
The QNAP TS-h2287XU-RP Rackmount NAS (3U) accommodates up to 22 SATA III drives of 2.5 or 3.5 inches, factory-configured with 0 TB and no drives installed, so you will need to add your own HDDs or SSDs to get started. Its Intel Xeon E-2336 processor at 2.9 GHz and 32 GB of DDR4 power the ZFS-based QuTS hero system, which supports RAID levels 0, 1, 5, 6, 10, 50, 60 and JBOD with online expansion and migration. This black and white variant includes hot-swap bays, automatic rebuild and compatibility with file systems such as ext4, NTFS or exFAT, among others. The 3U chassis with redundant power supply is designed for environments requiring advanced data management, although the unit is delivered without preinstalled storage capacity.
Specifications
Storage
- Storage drive interface: Serial ATA III
- Supported storage drive interfaces: Serial ATA III
- Storage drive sizes supported: 2.5, 3.5"
- System drive sizes supported: 3.5"
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10, 50, 60, JBOD
- Online RAID migration: Yes
- Online RAID expansion: Yes
- RAID rebuild: Yes
- Hot-swap drive bays: Yes
- Supported file systems: FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 22
- Supported storage drive types: HDD & SSD
- Auto-rebuild: Yes
- Disk roaming: Yes
Processor
- Processor manufacturer: Intel
- Processor family: Intel Xeon E
- Processor model: E-2336
- Processor frequency: 2.9 GHz
- Processor boost frequency: 4.8 GHz
- Processor cores: 6
- Processor threads: 12
- Processor cache: 12 MB
- CPU configuration (max): 1
Memory
- Internal memory: 32 GB
- Internal memory type: DDR4
- Maximum RAM supported: 128 GB
- Memory slots: 4
- Memory form factor: UDIMM
- ECC: Yes
- Flash memory: 5000 MB
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 100, 1000, 2500 Mbit/s
- Copper ethernet cabling technology: 10GBASE-T
- DHCP server: Yes
- iSCSI support: Yes
- Supported network protocols: IPv4, IPv6
- Dynamic DNS (DDNS): Yes
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- Ethernet LAN (RJ-45) ports: 4
- Number of SATA III connectors: 22
- PCI Express x8 (Gen 4.x) slots: 1
Design
- Chassis type: Rack (3U)
- Cooling type: Active
- Product colour: Black, White
- Number of fans: 4 fan(s)
- Fan diameter: 6 cm
- Fan diameter 2: 8 cm
- LED indicators: HDD, LAN, Status, USB
Performance
- Type: NAS
- Device class: Large Enterprise Business
- Backup function: Yes
- Backup features: Cloud, iSCSI LUN
- Multilingual support: Yes
- Number of users: 16000 user(s)
- Snapshot: Yes
- Management protocols: SMB/CIFS, AFP, NFS
- Web-based management: Yes
- Share folder access right management: Yes
- Security algorithms: HTTPS, SNMPv2, SNMPv3, SSH
- Access Control List (ACL): Yes
- Reset button: Yes
- On/off switch: Yes
- Built-in FTP server: Yes
- Browser supported: Apple Safari (latest version), Google Chrome (latest version), Microsoft Edge (latest version), Mozilla Firefox (latest version)
- System log: Yes
- Hot spare: Yes
- Disk scan: Yes
- S.M.A.R.T. support: Yes
- Share folder: Thick, Thin
Software
- Operating system installed: QuTS hero
- Operating system version: h5.0.0
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
- Linux operating systems supported: CentOS 7.0, Ubuntu 14.04, openSUSE 12.1, openSUSE 12.2
- Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
- Server operating systems supported: Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
- Other operating systems supported: IBM AIX 7.1, Solaris 10
Power
- Power supply location: Built-in
- Power supply unit (PSU) capacity: 550 W
- Number of power supply units: 2
- Redundant power supply (RPS) support: Yes
- Power consumption (typical): 228 W
- Power consumption (HDD standby): 165.39 W
Weight & dimensions
- Width: 483 mm
- Depth: 630 mm
- Height: 133 mm
- Weight: 15.6 kg
- Package weight: 22.1 kg
Packaging content
- Cables included: AC, LAN (RJ-45)
- Power cables quantity: 2
- Quick installation guide: Yes
- Number of screws: 128
Processor special features
- Embedded options available: No
- Enhanced Intel SpeedStep Technology: Yes
- Execute Disable Bit: Yes
- Idle States: Yes
- Intel 64: Yes
- Intel Trusted Execution Technology: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 70 °C
Other features
- Fibre Channel: Yes
