Description

Specifications

Display


  • Panel type: ADS
  • Display diagonal: 80 cm (31.5")
  • Display resolution: 1920 x 1080 pixels
  • Display brightness: 400 cd/m²
  • HD type: Full HD
  • Native aspect ratio: 16:9
  • Response time: 8 ms
  • Contrast ratio (typical): 1200:1
  • Contrast ratio (dynamic): 500000:1
  • Viewing angle, horizontal: 178°
  • Viewing angle, vertical: 178°
  • Display number of colours: 16.7 million colours
  • Pixel pitch: 0.36375 x 0.36375 mm
  • Display diagonal (metric): 80 cm
  • Native refresh rate: 60 Hz
  • Haze rate: 25%

Ports & interfaces


  • HDMI ports quantity: 2
  • HDMI version: 2.0
  • DVI port: Yes
  • DVI-I ports quantity: 1
  • USB port: Yes
  • USB ports quantity: 4
  • USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
  • Ethernet LAN (RJ-45) ports: 1
  • Audio (L/R) in: 1
  • Audio (L/R) out: 1
  • RS-232C: Yes
  • Card reader integrated: Yes
  • Compatible memory cards: MicroSD (TransFlash)

Audio


  • Built-in speaker(s): Yes
  • Number of built-in speakers: 2
  • RMS rated power: 10 W

Design


  • Product design: Digital signage flat panel
  • Placement supported: Indoor
  • Orientation: Horizontal/Vertical
  • Product colour: Black
  • Screen shape: Flat
  • VESA mounting: Yes
  • Panel mounting interface: 100 x 100, 200 x 200 mm
  • Bezel width (bottom): 1.19 cm
  • Bezel width (side): 1.19 cm
  • Bezel width (top): 1.19 cm

Performance


  • On Screen Display (OSD): Yes
  • Mean time between failures (MTBF): 50000 h

Power


  • Power consumption (typical): 26 W
  • Power consumption (standby): 0.5 W
  • Energy efficiency class (SDR): G
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50/60 Hz

Computer system


  • Computer system: Yes
  • Built-in processor: Yes
  • Processor manufacturer: ARM
  • Processor family: ARM Cortex
  • Processor model: A55
  • Internal memory: 3 GB
  • On-board graphics card model: ARM Mali-G52
  • Internal storage capacity: 16 GB
  • Operating system installed: Android 10
  • Video formats supported: H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP9
  • Audio formats supported: AAC, HE-AAC, MPEG
  • Image formats supported: BMP, JPEG, PNG, WEBP

Weight & dimensions


  • Display width: 726.5 mm
  • Display depth: 65.1 mm
  • Display height: 425.4 mm
  • Display weight: 5.7 kg

Packaging content


  • Remote control included: Yes
  • Batteries included: Yes
  • Cables included: Power, RS-232

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Operating relative humidity (H-H): 20 - 80%
  • Storage temperature (T-T): -20 - 60 °C
  • Storage relative humidity (H-H): 5 - 95%

Certificates


  • Certification: CB, CE, FCC, Class A, VCCI, RoHS, UL

Network


  • Ethernet LAN: Yes
