Owl Labs Owl Bar Video Conferencing Device — 4K Video Conferencing Bar with Active Speaker Focus (Add a Meeting Owl 3 or Pro for 360-Degree Coverage and Automatic Camera Switching)

Owl Labs Owl Bar Video Conferencing Device — 4K Video Conferencing Bar with Active Speaker Focus (Add a Meeting Owl 3 or Pro for 360-Degree Coverage and Automatic Camera Switching)

Name: Owl Labs Owl Bar Video Conferencing Device — 4K Video Conferencing Bar with Active Speaker Focus (Add a Meeting Owl 3 or Pro for 360-Degree Coverage and Automatic Camera Switching)
Brand: OWL LABS
Availability: OutOfStock

Not avaliable

More info

Amount

Brand: OWL LABS

SKU: 107172 PRC: 536064 EAN: 850022203961 PN: FRS100-2100

Description

Owl Labs Owl Bar Video Conferencing Device — 4K Video Conferencing Bar with Active Speaker Focus (Add a Meeting Owl 3 or Pro for 360-Degree Coverage and Automatic Camera Switching), Video collaboration bar, CMOS, 4K Ultra HD, 30 fps, Charcoal

Specifications

Performance

Number of cameras: 1
Product colour: Charcoal
Product type: Video collaboration bar

Video

HD type: 4K Ultra HD
Maximum video resolution: 3840 x 2160 pixels
Supported video modes: 360p, 1080p, 1440p, 2160p
Supported graphics resolutions: 640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
Maximum frame rate: 30 fps
Video formats supported: MJPG, NV12

Audio

Built-in speaker(s): Yes
Number of speakers: 1
Output level: 79/1 dB
RMS rated power: 5 W
Microphone pick-up range: 2.5 m

Ports & interfaces

HDMI ports quantity: 1
USB connector type: USB Type-C

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Wi-Fi: Yes
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms: WPA2, WPA3

Camera

Megapixel (approx.): 30 MP
Camera type: Single camera
Effective sensor resolution: 48 MP
Sensor type: CMOS
Focal length range: 500 - 5000 mm
Horizontal field of view: 114°
Vertical field of view: 73°

Microphone

Microphone sensitivity: 69 dB
Microphone frequency: 100 - 10000 Hz
Microphone direction type: Omnidirectional
Number of microphones: 4

Logistics data

Country of origin: Vietnam
Harmonized System (HS) code: 8525.5000.00

Computer system

Processor family: Qualcomm Snapdragon
Processor model: QCS8250
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Other operating systems supported: ChromeOS, Linux

Power

Power source type: DC
DC output voltage: 19 V

Certificates

Certified for Microsoft Teams: Yes

Weight & dimensions

Width: 97 mm
Depth: 769 mm
Height: 76 mm
Weight: 1.88 kg
Package width: 149 mm
Package depth: 820 mm
Package height: 162 mm
Package weight: 5 kg

Packaging content

Cables included: AC, USB Type-C
Wall mounting kit: Yes
Warranty card: Yes
Quick start guide: Yes
Packaging content: Owl Bar Table / Wall mount 6' USB Type C Cable Power supply AC line cord QSG Table card english Table card french Safety/regulat
