Description
The Neomounts DS70S-950WH1 monitor arm, from the brand NEWSTAR, is a cable and mounting accessory that supports screens from 17 to 49 inches with a maximum weight of 18 kg. This model in white features a gas spring system and a Topfix function that allows the display to be rotated up to 180 degrees for easy position adjustment. It is installed on the desk via clamp or screw mounting, with a table thickness of between 1 and 5.5 cm, and offers an adjustable depth ranging from 11.9 to 65.6 cm from the wall. Compatible with 75x75 and 100x100 mm mounting interfaces, this bracket supports a single screen, with a reduced capacity of 15 kg for curved or large-format models.
Specifications
Mounting
- Maximum weight capacity (per display): 18 kg
- Maximum weight capacity: 18 kg
- Minimum screen size: 43.2 cm (17")
- Number of displays supported: 1
- Maximum weight capacity (per curved/ultra-wide display): 15 kg
- Maximum screen size: 124.5 cm (49")
- Mounting: Clamp/Grommet
- Mounting type: Desk
- Minimum VESA mount: 75 x 75 mm
- Maximum VESA mount: 100 x 100 mm
- Panel mounting interface: 100 x 100, 75 x 75 mm
- Desk thickness (min): 1 cm
- Desk thickness (max): 5.5 cm
- Clamp mount desk thickness (max): 5 cm
- Grommet mount desk thickness (max): 5.5 cm
- Distance to the wall (min): 11.9 cm
- Distance to the wall (max): 65.6 cm
Ergonomics
- Width adjustment: 107.4 cm
- Pivot angle: -180 - 180°
- Height adjustment: Yes
- Height adjustment type: Gas spring
- Height adjustment range: 200 - 520 mm
- Adjustable depth: Yes
- Depth adjustment range: 88 - 625 mm
- Tilt adjustment: Yes
- Tilt angle range: -90 - 90°
- Swivelling: Yes
- Swivel angle range: -90 - 90°
- Rotating: Yes
- Angle of rotation: 360°
- Number of arms: 1
- Cable management: Yes
Design
- Housing material: Aluminium
- Product colour: White
- Easy to install: Yes
Weight & dimensions
- Width: 135 mm
- Depth: 656 mm
- Height: 579 mm
- Weight: 3.72 kg
Packaging data
- Package width: 333 mm
- Package depth: 122 mm
- Package height: 423 mm
- Package net weight: 4.3 kg
- Package weight: 4.3 kg
- Package type: Box
Other features
- Minimum weight: 1 kg
- Width adjustment range: 0 - 1074 mm
- Warranty period: 10 year(s)
Logistics data
- Master (outer) case net weight: 15 kg
- Harmonized System (HS) code: 7326909890
- Products per pallet (EU): 80 pc(s)
- Master (outer) case width: 355 mm
- Master (outer) case length: 290 mm
- Master (outer) case height: 490 mm
- Master (outer) case gross weight: 18.1 kg
- Products per master (outer) case: 4 pc(s)
- Country of origin: China
