Description
MSI Cubi 5 12M-001EU, 3.5 GHz, Intel® Core™ i7, i7-1255U, 16 GB, 512 GB, Windows 11 Home
Specifications
Processor
- Processor threads: 12
- Processor frequency: 3.5 GHz
- Performance cores: 2
- Efficient cores: 8
- Performance-core Max Turbo Frequency: 4.7 GHz
- Efficient-core Max Turbo Frequency: 3.5 GHz
- Processor cache: 12 MB
- Processor cache type: Smart Cache
- Configurable TDP-down: 12 W
- Number of processors installed: 1
- Processor base power: 15 W
- Maximum turbo power: 55 W
- Processor manufacturer: Intel
- Processor family: Intel® Core™ i7
- Processor generation: 12th gen Intel® Core™ i7
- Processor model: i7-1255U
- Processor cores: 10
Memory
- Internal memory: 16 GB
- Maximum internal memory: 64 GB
- Internal memory type: DDR4-SDRAM
- Memory layout (slots x size): 2 x 8 GB
- Memory slots: 2x SO-DIMM
- Memory clock speed: 3200 MHz
Storage
- Total storage capacity: 512 GB
- Storage media: SSD
- Optical drive type: No
- Total SSDs capacity: 512 GB
- Number of SSDs installed: 1
- SSD capacity: 512 GB
- SSD interface: PCI Express 4.0
- NVMe: Yes
- SSD form factor: M.2
Graphics
- Discrete graphics card: No
- On-board graphics card: Yes
- Discrete graphics card model: Not available
- On-board GPU manufacturer: Intel
- On-board graphics card family: Intel Iris Xe Graphics
- On-board graphics card model: Intel Iris Xe Graphics
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Cabling technology: 10/100/1000Base-T(X)
- LAN controller: Realtek RTL8111H
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Wi-Fi standards: Wi-Fi 6 (802.11ax)
- Antenna type: 2x2
- Bluetooth: Yes
- Bluetooth version: 5.2
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- Intel® Thunderbolt 4: Yes
- Thunderbolt 4 ports quantity: 1
- HDMI ports quantity: 1
- HDMI version: 2.0b
- DisplayPorts quantity: 1
- DisplayPort version: 1.4
- Ethernet LAN (RJ-45) ports: 1
- Combo headphone/mic port: Yes
- DC-in jack: Yes
Design
- Chassis type: Mini PC
- Volume: 0.66 L
- Placement supported: Horizontal/Vertical
- VESA mounting: Yes
- Cable lock slot: Yes
- Product colour: Black
Performance
- Market positioning: Business
- Motherboard chipset: Intel SoC
- Product type: Mini PC
Software
- Operating system installed: Windows 11 Home
- Bundled software: MSI Center: Hardware Monitoring, Free Up Memory, Clean Up Disk, LAN Manager, MSI Recovery, F3 Recovery, Devices Speed Up, Smart
Processor special features
- Embedded options available: No
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel Trusted Execution Technology: Yes
- Execute Disable Bit: Yes
- Intel Flex Memory Access: Yes
- CPU configuration (max): 1
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Virtualization Technology (VT-x): Yes
Power
- Power supply: 65 W
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC)
Weight & dimensions
- Width: 124 mm
- Depth: 124 mm
- Height: 53.7 mm
- Weight: 550 g
- Package weight: 1.4 kg
Packaging content
- Cables included: AC, Power
- Screws included: Yes
Display
- Display included: No
