Description
Intel Xeon E-2374G processor in box format, with four cores and eight execution threads reaching a turbo frequency of 5 GHz on a base of 3.7 GHz. Its 8 MB Smart Cache and 8 GT/s bus facilitate the management of demanding workloads on servers or workstations with an LGA 1200 socket. Manufactured with 14 nm lithography, this 64-bit model has a TDP of 80 W and does not include a cooler, so you will need a compatible cooling system for its installation.
Specifications
Processor
- Processor manufacturer: Intel
- Processor model: E-2374G
- Processor base frequency: 3.7 GHz
- Processor family: Intel Xeon E
- Processor cores: 4
- Processor socket: LGA 1200 (Socket H5)
- Component for: Server/workstation
- Processor lithography: 14 nm
- Processor threads: 8
- System bus rate: 8 GT/s
- Processor operating modes: 64-bit
- Processor boost frequency: 5 GHz
- Processor cache: 8 MB
- Processor cache type: Smart Cache
- Thermal Design Power (TDP): 80 W
- Package type: Box
- Cooler included: No
- Processor ARK ID: 212260
Memory
- Memory types supported by processor: DDR4-SDRAM
- Memory channels: Dual-channel
- ECC: Yes
Graphics
- On-board graphics card: Yes
- Discrete graphics card: No
- On-board graphics card model: Intel UHD Graphics P750
- Maximum on-board graphics card memory: 64 GB
- On-board graphics card base frequency: 350 MHz
- On-board graphics card dynamic frequency (max): 1300 MHz
- On-board graphics card 4K support: Yes
- On-board graphics card OpenGL version: 4.5
- On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
- On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
- On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
- Discrete graphics card model: Not available
- Number of execution units: 32
Features
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Server
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 4.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4, 1x8+3x4
- Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0, AVX-512
- Scalability: 1S
- CPU configuration (max): 1
- Export Control Classification Number (ECCN): 5A992CN3
- Commodity Classification Automated Tracking System (CCATS): G167599
- Execute Disable Bit: Yes
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® Quick Sync Video Technology: Yes
- Intel® InTru™ 3D Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Memory Protection Extensions (Intel® MPX): Yes
- Intel® Turbo Boost Technology 2.0 frequency: 5 GHz
- Intel® Transactional Synchronization Extensions: No
- Maximum Enclave Size Support for Intel® SGX: 0.5 GB
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel Clear Video Technology: Yes
- Intel Software Guard Extensions (Intel SGX): Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® Boot Guard: Yes
- Intel® Optane™ DC Persistent Memory Supported: No
- Intel® vPro™ Platform Eligibility: Yes
Operational conditions
- Tjunction: 100 °C
Technical details
- Launch date: Q3'21
- Status: Launched
- Supported memory types: DDR4-SDRAM
- Servicing status: Baseline Servicing
Logistics data
- Harmonized System (HS) code: 85423119
Weight & dimensions
- Processor package size: 37.5 x 37.5 mm
Other features
- Maximum internal memory: 128 GB
