Description
Intel Xeon Gold 6248R processor in tray presentation, a model from the 2nd generation Scalable Xeon family with 24 cores and 48 execution threads. Its base frequency is 3 GHz, reaching 4 GHz in turbo mode, and it has a 35.75 MB cache. Designed for servers and workstations, this 64-bit processor uses the LGA 3647 socket and features a 14nm lithography, based on the Cascade Lake architecture. With a TDP of 205 W, it does not include a cooler and is intended for professional environments requiring high processing performance.
Specifications
Processor
- Processor manufacturer: Intel
- Processor generation: 2nd Generation Intel® Xeon® Scalable
- Processor model: 6248R
- Processor base frequency: 3 GHz
- Processor family: Intel® Xeon® Gold
- Processor cores: 24
- Processor socket: LGA 3647 (Socket P)
- Component for: Server/workstation
- Processor lithography: 14 nm
- Processor threads: 48
- Processor operating modes: 64-bit
- Processor boost frequency: 4 GHz
- Processor cache: 35.75 MB
- Thermal Design Power (TDP): 205 W
- Package type: Tray
- Cooler included: No
- Processor codename: Cascade Lake
- Processor ARK ID: 199351
Memory
- Maximum internal memory supported by processor: 1.02 TB
- Memory types supported by processor: DDR4-SDRAM
- Memory clock speeds supported by processor: 2933 MHz
- Memory channels: Hexa-channel
- ECC: Yes
Graphics
- On-board graphics card: No
- Discrete graphics card: No
- On-board graphics card model: Not available
- Discrete graphics card model: Not available
Features
- Execute Disable Bit: Yes
- Market segment: Server
- Maximum number of PCI Express lanes: 48
- PCI Express slots version: 3.0
- Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512
- Scalability: 2S
- Embedded options available: No
- PCI Express CEM revision: 3.0
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): G077159
Processor special features
- Intel® Speed Select technology - Performance Profile (Intel® SST-PP): No
- Intel® Resource Director Technology (Intel® RDT): Yes
- Intel® Volume Management Device (VMD): Yes
- Intel® Run Sure Technology: Yes
- Mode-based Execute Control (MBE): Yes
- Intel® Optane™ DC Persistent Memory Supported: Yes
- Intel® vPro™ Platform Eligibility: Yes
- Intel Speed Select Technology (SST): No
- Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): No
- Intel® Optane™ DC Persistent Memory technology: Yes
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Transactional Synchronization Extensions: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: No
- AVX-512 Fused Multiply-Add (FMA) units: 2
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Operational conditions
- Tcase: 75 °C
Technical details
- Launch date: Q1'20
- Product type: Processor
- Status: Launched
- Supported memory types: DDR4-SDRAM
- Memory speed (max): 2933 MHz
- Number of UPI links: 2
- Servicing status: Baseline Servicing
Logistics data
- Harmonized System (HS) code: 85423119
Weight & dimensions
- Processor package size: 76mm x 56.5mm
Other features
- Maximum internal memory: 1 TB
