Description
The Intel E810-XXVDA2 network card for OCP 3.0 offers fibre connectivity with two SFP28 ports and a PCI Express 4.0 host interface, being an internal component designed for servers. It incorporates the Intel E810 controller and supports transfer speeds of 1000, 10000 and 25000 Mbit/s, thus covering Gigabit Ethernet, 10 Gigabit Ethernet and 25 Gigabit Ethernet. Its compact format, with a width of 115 mm and a depth of 76 mm, facilitates integration into chassis. The product is available in black, green and silver, and operates correctly in a temperature range of 0 to 65 °C.
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: PCI Express
- Interface: Fiber
- Fiber ports quantity: 2
- Fiber optic connector: SFP28
- PCI version: 4.0
Network
- Ethernet interface type: 10 Gigabit Ethernet, 25 Gigabit Ethernet, Gigabit Ethernet
- Ethernet LAN data rates: 1000, 10000, 25000 Mbit/s
- LAN controller: Intel E810
Design
- Component for: Server
- Product colour: Black, Green, Silver
- Internal: Yes
- Certification: FCC A, UL, CE, VCCI, BSMI, RCM, KCC
Operational conditions
- Operating temperature (T-T): 0 - 65 °C
- Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
- Width: 115 mm
- Depth: 76 mm
Logistics data
- Harmonized System (HS) code: 8517620090
Other features
- Cable type: SFP28 ports - DAC, Optics, And AOC's
- Market segment: Server
- Intel Virtual Machine Device Queues (VMDq): Yes
- PCI-SIG* SR-IOV Capable: Yes
- On-chip QoS and Traffic Management: Yes
- Intel Flexible Port Partitioning: Yes
- Speed & slot width: 16.0 GT/s, x8 Lane
- Intelligent Offloads: Yes
- iWARP/RDMA: Yes
- Intel Data Direct I/O Technology: Yes
- Intel Virtualization Technology for Connectivity (VT-c): Yes
- Processor family: 25GbE Intel Ethernet Network Adapter E810-25GbE Intel Ethernet Network Adapter E810
- Storage Over Ethernet: iSCSI, NFS
- Launch date: Q3'20
- Network interface card cable medium: Copper, Fiber
- Network interface card type: Server
- Status: Launched
- Ethernet adapter ARK ID: 184815
- Export Control Classification Number (ECCN): 5A991
- Commodity Classification Automated Tracking System (CCATS): NA
- Bracket height: OCP 3.0
- Product series: 800 Series Network Adapters (up to 100GbE)
