Description
12th generation Intel Core i9-12900 processor in box format, with 16 cores (8 performance and 8 efficiency) and 24 execution threads. It reaches a maximum turbo frequency of 5.1 GHz, with acceleration up to 5 GHz on the performance cores and 3.8 GHz on the efficient ones, and its maximum turbo power is 202 W. This Alder Lake architecture model operates in 64-bit mode and supports a maximum memory bandwidth of 76.8 GB/s. Includes a cooler in the box, ready to install in your system.
Specifications
Processor
- Processor manufacturer: Intel
- Processor generation: 12th gen Intel® Core™ i9
- Processor model: i9-12900
- Processor family: Intel® Core™ i9
- Processor cores: 16
- Processor socket: LGA 1700
- Processor threads: 24
- Processor operating modes: 64-bit
- Performance cores: 8
- Efficient cores: 8
- Processor boost frequency: 5.1 GHz
- Performance-core boost frequency: 5 GHz
- Performance-core base frequency: 2.4 GHz
- Efficient-core boost frequency: 3.8 GHz
- Efficient-core base frequency: 1.8 GHz
- Processor cache: 30 MB
- Processor cache type: Smart Cache
- Package type: Box
- Cooler included: Yes
- Processor base power: 65 W
- Maximum turbo power: 202 W
- Stepping: C0
- Bus type: DMI4
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 76.8 GB/s
- Processor codename: Alder Lake
- Processor ARK ID: 134597
Memory
- Maximum internal memory supported by processor: 128 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- ECC: Yes
- Non-ECC: Yes
- Memory bandwidth (max): 76.8 GB/s
Graphics
- On-board graphics card: Yes
- Discrete graphics card: No
- On-board graphics card model: Intel UHD Graphics 770
- On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
- On-board graphics card base frequency: 300 MHz
- On-board graphics card dynamic frequency (max): 1550 MHz
- Number of displays supported (on-board graphics): 4
- On-board graphics card DirectX version: 12.0
- On-board graphics card OpenGL version: 4.5
- On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
- On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
- On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
- On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
- On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
- On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
- On-board graphics card ID: 0x4680
- Discrete graphics card model: Not available
- Number of execution units: 32
- Multi-Format Codec Engines: 2
Features
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: PC/Client/Tablet, Workstation
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 5.0, 4.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Direct Media Interface (DMI) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992CN3
- Commodity Classification Automated Tracking System (CCATS): G167599
Processor special features
- Intel® Quick Sync Video Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Turbo Boost Max Technology 3.0 frequency: 5.1 GHz
- Intel® Total Memory Encryption: Yes
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® Active Management Technology (Intel® AMT): Yes
- Intel Stable Image Platform Program (SIPP): Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- Intel® Optane™ Memory Ready: Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® vPro™ Platform Eligibility: Yes
- Intel® Standard Manageability (ISM): Yes
- Intel® One-Click Recovery: Yes
- Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel vPro® Enterprise Platform Eligibility: Yes
- Intel® Threat Detection Technology (TDT): Yes
- Intel® Hardware Shield Eligibility: Yes
- Intel® Total Memory Encryption - Multi Key: Yes
- Intel vPro® Essentials Platform Eligibility: Yes
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
Operational conditions
- Tjunction: 100 °C
Technical details
- Target market: Gaming, Content Creation
- OpenCL version: 2.1
- Launch date: Q1'22
- Status: Launched
Logistics data
- Harmonized System (HS) code: 85423119
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- Maximum internal memory: 128 GB
- Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
