Description
The Gembird UPS from the EG-UPSRACK-13 series, with a specific reference for rack mounting, provides an output power of 1800 W and 3 kVA in a line-interactive topology. It features seven C13-type AC outlets and a C14 input connector, plus a USB 2.0 port for management, and its sine wave ensures stable power delivery. It includes protection against overload, short circuit, and excessive discharge, with a response time of 10 ms, while its automatic voltage regulation (AVR) efficiently corrects grid fluctuations at 85%. With a noise level of 45 dB and an audible alarm, this unit autonomously and quietly protects your critical devices.
Specifications
Features
- UPS topology: Line-Interactive
- Output power capacity: 3 kVA
- Output power: 1800 W
- Waveform: Sine
- Input frequency: 50/60 Hz
- Automatic Voltage Regulation (AVR): Yes
- Response time: 10 ms
- Efficiency: 85%
- Output power factor: 0.8
- Noise level: 45 dB
- Surge protection: Yes
- Power protection features: Overcharge, Overdischarge, Short circuit
- Audible alarm(s): Yes
Ports & interfaces
- AC outlet types: C13 coupler
- Power plug: C14 coupler
- AC outlets quantity: 7 AC outlet(s)
- Number of type F outputs: 1
- USB 2.0 ports quantity: 1
Battery
- Battery technology: Sealed Lead Acid (VRLA)
- Battery capacity: 9 Ah
- Battery voltage: 12 V
- Number of batteries supported: 4
- Battery recharge time: 12 h
- Cold start: Yes
Design
- Form factor: Rackmount/Tower
- Housing material: Metal
- Cooling type: Active
- Display type: LED
- LED indicators: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 10 - 90%
Certificates
- Compliance certificates: RoHS
- Certification: ISO 9002, CE
Packaging content
- Cables included: USB cable
Weight & dimensions
- Width: 410 mm
- Depth: 430 mm
- Height: 132 mm
- Weight: 28.1 kg
Packaging data
- Package width: 525 mm
- Package depth: 410 mm
- Package height: 225 mm
- Package weight: 30.4 kg
Logistics data
- Harmonized System (HS) code: 85078000
Other features
- Output connections: 6 x C13, 1 x Schuko EU
- Nominal output voltage: 220 V
- Nominal input voltage: 220 V
