Name: EZVIZ EP7 video intercom system 17.8 cm (7'') Black, Silver
Brand: EZVIZ
Availability: OutOfStock

EZVIZ EP7 video intercom system 17.8 cm (7'') Black, Silver

Not avaliable

Amount

Brand: EZVIZ

SKU: 106555 PRC: 528155 EAN: 6941545631363 PN: CS-EP7-R100-1W2HTFC

Description

Specifications

Technical details

Connectivity technology: Wired & Wireless
Colour: Yes
Speakerphone: Yes
Number of displays supported: 1
Maximum number of cameras supported: 1
Frequency band: 2.4/5 GHz
Built-in microphone: Yes
RFID reader: Yes
Sustainability compliance: Yes
Compliance certificates: CE, REACH, RoHS, WEEE

Display

Display diagonal: 17.8 cm (7")
Display resolution: 1024 x 600 pixels
Backlight display: Yes
Touchscreen: Yes
Video formats supported: H.264, H.265

Camera

Maximum image resolution: 2048 x 1296 pixels
Image quality adjustment: DNR
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Maximum frame rate: 15 fps
Motion sensor: Yes
Viewing angle, diagonal: 162°
Day/night mode: Yes

Night vision

Night vision: Yes
Night vision distance: 6 m
LED type: IR

Audio

Built-in speaker(s): Yes
Audio system: 2-way
Number of ringtones: 20

Design

Product colour: Black, Silver
International Protection (IP) code: IP65
Control type: Buttons, Remote, Touch
Proper use: Indoor & outdoor
Waterproof: Yes

Storage

Memory card slot: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB

Indoor unit

Channel bandwidth: 20 MHz

Network

Wi-Fi: Yes
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards: IEEE 802.11ah
Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK

Power

Indoor unit power type: DC
Outdoor unit power type: Solar
Battery technology: Lithium
Battery capacity: 2600 mAh
Battery voltage: 7.3 V
Battery life: 85 day(s)
Power consumption (max): 24 W

Operational conditions

Operating temperature (T-T): -20 - 50 °C
Operating relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 86.4 mm
Depth: 33.8 mm
Height: 175.5 mm
Weight: 675 g
Power supply dimensions (WxDxH): 55.9 x 44.2 x 126.4 mm
Door station dimensions (WxDxH): 180 x 15 x 112 mm

Packaging data

Indoor unit included: Yes
Outdoor unit included: Yes
Mounting kit: Yes
Rain cover: Yes
Package weight: 1.86 kg

Packaging content

Packaging content: - Monitor - Wall Bracket for Monitor - Power Adapter for Monitor - Intercom Panel (Doorbell) with a Weather-proof Shield - Drill
Screws included: Yes
Cables included: USB
Quick start guide: Yes

Battery

Rechargeable battery: Yes
