Elo Touch Solutions 1302L 33.8 cm (13.3'') LCD 270 cd/m² Full HD White Touchscreen

$496.09

$496.09 without VAT

Amount

Brand: ELO TOUCH SOLUTIONS

SKU: 91215 PRC: 352341 EAN: 843173109381 PN: e683396

Description

Specifications

Display

Panel type: TFT
Display diagonal: 33.8 cm (13.3")
Display technology: LCD
Display resolution: 1920 x 1080 pixels
Display brightness: 270 cd/m²
HD type: Full HD
Touchscreen: Yes
Touchscreen technology: Projected capacitive system
Number of simultaneous touchpoints: 10
Native aspect ratio: 16:9
Response time: 25 ms
Contrast ratio (typical): 800:1
Viewing angle, horizontal: 170°
Viewing angle, vertical: 170°
Display number of colours: 16.78 million colours
Horizontal scan range: 30 - 75 kHz
Supported graphics resolutions: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 136

Ports & interfaces

HDMI ports quantity: 1
HDMI version: 1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1

Audio

Built-in speaker(s): Yes
RMS rated power: 2 W

Design

Product colour: White
Screen shape: Flat
VESA mounting: Yes
Panel mounting interface: 75 x 75 mm

Performance

On Screen Display (OSD): Yes
International Protection (IP) code: IPX1
Mean time between failures (MTBF): 50000 h

Power

Power consumption (typical): 9.8 W
Power consumption (off): 0.18 W
AC input voltage: 100 - 240 V
AC input frequency: 50 / 60 Hz

Weight & dimensions

Width (with stand): 326.1 mm
Depth (with stand): 150 mm
Height (with stand): 259.6 mm
Weight (with stand): 2.32 kg

Packaging data

Package width: 405 mm
Package depth: 160 mm
Package height: 280 mm
Package weight: 2.89 kg

Packaging content

Cables included: AC, HDMI, USB

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 90%

Certificates

Certification: Australia RCM Canada cUL, IC China CCC Europe CE Japan VCCI Korea KCC Mexico NOM Taiwan BSMI United States UL, FCC International

Logistics data

Harmonized System (HS) code: 85285210

Features

Wall mountable: Yes

Technical details

Compliance certificates: RoHS

Other features

Audio input: 1
Viewable size, horizontal: 29.4 cm
Viewable size, vertical: 16.5 cm
Height (without stand): 211.3 mm
Weight (without stand): 1.22 kg
Depth (without stand): 25.1 mm
Power supply type: AC
Built-in camera: No
