Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® Core™ i5 8 GB DDR4-SDRAM 128 GB SSD Black All-in-One tablet PC

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel®

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® — image 2 of 5

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® — image 3 of 5

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® — image 4 of 5

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® — image 5 of 5

Elo Touch Solution I-Series E692244 All-in-One PC/workstation 39.6 cm (15.6'') 1920 x 1080 pixels Touchscreen 8th gen Intel® Core™ i5 8 GB DDR4-SDRAM 128 GB SSD Black All-in-One tablet PC

Elo Touch Solution I-Series E692244, 39.6 cm (15.6"), Full HD, 8th gen Intel® Core™ i5, 8 GB, 128 GB, Windows 10.

More info

Brand: ELO TOUCH SOLUTION

Not avaliable

Stock available: 0 units.

Unavailable

SKU: 83494 PRC: 270663 EAN: 843173109442 PN: e692244

Description

The 39.6 cm (15.6") Elo Touch Solution I-Series all-in-one is a device with a Full HD flat-format touchscreen and a 16:9 aspect ratio. Its multi-touch screen, with LED backlighting and 25 ms response time, offers a resolution of 1920 x 1080 pixels to work precisely on the surface itself. It incorporates an 8th generation Intel Core i5 processor at 2.1 GHz, with turbo frequency of 3.5 GHz, six threads and Intel Q370 chipset, together with 8 GB of DDR4-SDRAM memory and a 128 GB SSD. The device is black, weighs 2.2 kg and measures 384.2 x 246.4 x 43.8 mm (width x height x depth), so it integrates easily into counters and customer service stations.

Specifications

Display

Display diagonal: 39.6 cm (15.6")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
LED backlight: Yes
3D: No
Touchscreen: Yes
Touch technology: Multi-touch
Aspect ratio: 16:9
Display response rise/fall: 25 ms
Detachable display: No
Screen shape: Flat

Processor

Processor frequency: 2.1 GHz
Processor model: i5-8500T
Processor family: 8th gen Intel® Core™ i5
Processor boost frequency: 3.5 GHz
Processor cores: 6
Processor threads: 6
Processor cache: 9 MB
Processor cache type: Smart Cache
System bus rate: 8 GT/s
64-bit computing: Yes
Motherboard chipset: Intel Q370
PCI Express slots version: 3.0
Processor lithography: 14 nm
Bus type: DMI3
Thermal Design Power (TDP): 35 W
Maximum number of PCI Express lanes: 16
Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR4-SDRAM
Memory clock speeds supported by processor: 2666 MHz
Memory bandwidth supported by processor (max): 41.6 GB/s
Memory channels supported by processor: Dual
ECC supported by processor: No

Memory

Internal memory: 8 GB
Maximum internal memory: 32 GB
Internal memory type: DDR4-SDRAM
Memory slots: 2
Memory slots type: SO-DIMM
Memory clock speed: 2666 MHz
Memory layout (slots x size): 1 x 8 GB

Storage

Card reader integrated: No
Total SSDs capacity: 128 GB
Number of SSDs installed: 1
SSD capacity: 128 GB
SSD form factor: M.2
Total storage capacity: 128 GB
Storage media: SSD

Graphics

Discrete graphics adapter: No
Discrete graphics adapter model: Not available
On-board graphics adapter: Yes
On-board graphics adapter family: Intel® UHD Graphics
On-board graphics adapter model: Intel® UHD Graphics 630
On-board graphics adapter DirectX version: 12.0
On-board graphics adapter OpenGL version: 4.5
On-board graphics adapter 4K support: Yes

Audio

Built-in speaker(s): Yes
Number of speakers: 2
RMS rated power: 2 W

Optical drive

Optical drive type: No

Network

Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Bluetooth: Yes
Bluetooth version: 5.0

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Headphone outputs: 1

Design

Product colour: Black
VESA mounting: Yes
Panel mounting interface: 75 x 75 mm

Performance

Product type: All-in-One tablet PC
Trusted Platform Module (TPM): Yes

Software

Operating system installed: Windows 10

Power

AC adapter power: 100 W
AC adapter frequency: 50-60 Hz
AC adapter input voltage: 100 - 240 V

Multimedia

Built-in camera: No

Pen

Pen included: No

Weight & dimensions

Width: 384.2 mm
Depth: 43.8 mm
Height: 246.4 mm
Weight: 2.2 kg

Packaging data

Package width: 462 mm
Package depth: 216 mm
Package height: 346 mm
Package weight: 4.3 kg

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 5 - 95%
