Processor


  • Processor manufacturer: Intel
  • Processor family: Intel Xeon E
  • Processor model: E-2334
  • Processor frequency: 3.4 GHz
  • Processor boost frequency: 4.8 GHz
  • Processor cores: 4
  • Processor cache: 8 MB
  • Number of processors installed: 1
  • Execute Disable Bit: Yes
  • Idle States: Yes

Memory


  • Internal memory: 16 GB
  • Internal memory type: DDR4-SDRAM
  • Buffered memory type: Unregistered (unbuffered)
  • Memory slots: 4x DIMM
  • ECC: Yes
  • Memory layout (slots x size): 1 x 16 GB
  • Memory data transfer rate: 3200 MT/s
  • Maximum internal memory: 128 GB

Storage


  • Total storage capacity: 600 GB
  • Number of HDDs installed: 1
  • HDD capacity: 600 GB
  • HDD interface: Serial Attached SCSI (SAS)
  • HDD speed: 10000 RPM
  • HDD size: 2.5"
  • RAID support: No
  • Supported RAID controllers: PERC H355
  • Hot-Plug support: Yes
  • Optical drive type: No

Graphics


  • On-board graphics card: No
  • On-board graphics card model: Not available

Network


  • Wi-Fi: No
  • LAN controller: Broadcom 5720
  • Ethernet LAN: Yes
  • Cabling technology: 10/100/1000Base-T(X)
  • Ethernet interface type: Gigabit Ethernet

Ports & interfaces


  • Ethernet LAN (RJ-45) ports: 2
  • USB 2.0 ports quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
  • VGA (D-Sub) ports quantity: 1

Expansion slots


  • PCI Express x8 slots: 1
  • PCI Express x16 slots: 1

Design


  • Chassis type: Rack (1U)
  • Product colour: Black
  • Rack mounting: Yes
  • Rack rails: Yes

Performance


  • Remote administration: iDRAC9 Express 15G

Software


  • Operating system installed: No
  • Compatible operating systems: Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterpri

Processor special features


  • CPU configuration (max): 1
  • Enhanced Intel SpeedStep Technology: Yes
  • Intel Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel Trusted Execution Technology: Yes
  • Intel VT-x with Extended Page Tables (EPT): Yes
  • Intel Software Guard Extensions (Intel SGX): Yes
  • Intel 64: Yes
  • Intel Virtualization Technology (VT-x): Yes

Power


  • Redundant power supply (RPS) support: Yes
  • Power supply: 600 W
  • Number of redundant power supplies supported: 2
  • Number of redundant power supplies installed: 2
  • Power cable length: 2 m
  • Power cable connector 1: C13 coupler
  • Power cable connector 2: C14 coupler
  • Power cable current: 10 A

Operational conditions


  • Storage temperature (T-T): -40 - 65 °C
  • Storage relative humidity (H-H): 5 - 95%
  • Operating altitude: 0 - 3048 m
  • Non-operating altitude: 0 - 12000 m

Logistics data


  • Harmonized System (HS) code: 84714100

Carbon footprint


  • Total carbon footprint (kg of CO2e): 2410
  • Total carbon emissions, standard deviation (kg of CO2e): 1160
  • Carbon emissions, manufacturing (kg of CO2e): 451
  • Carbon emissions, logistics (kg of CO2e): 107
  • Carbon emissions, energy usage (kg of CO2e): 1840
  • Carbon emissions, end-of-life (kg of CO2e): 17
  • Total carbon emissions, w/o use phase (kg of CO2e): 575
  • PAIA version: 1.3.2, 2022

Weight & dimensions


  • Width: 434 mm
  • Height: 42.8 mm
