Description
The Brother PT-H500 label printer prints with a maximum resolution of 180 x 180 DPI and a speed of 30 mm/s, with a label width of up to 2.4 cm and a print height of 1.8 cm. Its wired connection, via a USB 2.0 port, allows direct use from the PC, and its auto-cutter facilitates automatic tape cutting. It incorporates functions such as vertical printing, underlining, 14 characters and 10 styles, in addition to supporting BMP, JPG and TIF image formats. It handles TZe labels and features a QWERTY keyboard for simple operation.
Specifications
Printing
- Maximum resolution: 180 x 180 DPI
- Print speed: 30 mm/sec
- Maximum printing width: 2.4 cm
- Maximum print height: 1.8 cm
- Vertical printing: Yes
Paper handling
- Autocutter: Yes
- Maximum label width: 2.4 cm
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: No
- Wi-Fi: No
- USB port: Yes
- PC connected: Yes
- USB 2.0 ports quantity: 1
Performance
- Built-in barcodes: CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, GS1-128, ITF, UPC-A, UPC-E
- Number of fonts: 14
- Tape type: TZe
- Tape cutting: Automatic
- Image formats supported: BMP, JPG, TIF
- Number of styles: 10
- Number of printing lines (max): 7
- Underline: Yes
Design
- Product colour: Black
- Built-in display: Yes
- Display: LCD
- Backlight display: Yes
- Display number of lines: 3 lines
- Display number of characters: 16
- Keyboard layout: QWERTY
Power
- Number of batteries supported: 6
- Auto power off: Yes
- Rechargeable: Yes
System requirements
- Windows operating systems supported: Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Wind
- Mac operating systems supported: Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Weight & dimensions
- Width: 305 mm
- Depth: 125 mm
- Height: 300 mm
- Weight: 995 g
Packaging data
- Package weight: 1.65 kg
Packaging content
- Cables included: USB
- Quick start guide: Yes
Logistics data
- Products per pallet: 90 pc(s)
- Harmonized System (HS) code: 84433210
- Pallet gross height: 17.5 cm
- Pallet gross weight: 169.2 kg
- Master (outer) cases per pallet: 30 pc(s)
- Master (outer) cases per pallet layer: 6 pc(s)
- Layers per pallet: 5 pc(s)
Technical details
- Pallet type: 800 x 1200 mm
Other features
- Print preview: Yes
- Label memory: 50 label(s)
- Country of origin: China
- Number of frames: 99
- Spare part retention: 5 year(s)
