Description

Specifications

Technical details


  • Connectivity technology: Wired
  • Colour: Yes
  • Speakerphone: Yes
  • Maximum number of cameras supported: 1
  • Maximum indoor range: 5 m
  • Contrast adjustment: Yes
  • Door station control: Yes
  • VoIP protocols: secondary SIP server, IPv6, SRTP, SIPS, SIP TLS, DTMF (RFC2976 and RFC2833), NAT (ICE, STUN, TURN), Contact list, parallel call
  • Streaming capability: Yes
  • Echo cancellation: Yes
  • Wall mountable: Yes
  • Built-in microphone: Yes
  • Automatic gain control: Yes
  • Motion detection function: Yes
  • Relay inputs: 1

Camera


  • Megapixel (approx.): 5 MP
  • Maximum video resolution: 2592 x 1944 pixels
  • Sensor type: CMOS
  • Maximum frame rate: 30 fps
  • PTZ control: Yes
  • Viewing angle, horizontal: 140°
  • Viewing angle, vertical: 114°

Night vision


  • Night vision: Yes
  • LED type: IR

Audio


  • Built-in speaker(s): Yes
  • Number of speakers: 1
  • Noise-canceling: Yes
  • Voice codecs: G.722, G.726-32, OPUS, PCM, PCMA

Design


  • Product colour: Black
  • On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russia
  • International Protection (IP) code: IP66, IP69
  • IK code: IK10
  • Number of OSD languages: 12
  • Vandal-proof: Yes
  • Housing material: Plastic, Stainless steel, Zinc
  • Control type: Wireless
  • Proper use: Outdoor

Network


  • Power over Ethernet (PoE): Yes
  • Supported network protocols: IPv4, IPv6 USGv6, HTTP, HTTPSa , HTTP/2, SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v
  • Networking standards: IEEE 802.3af, IEEE 802.3at

Management features


  • Syslog: Yes

Power


  • Operating voltage (door opener): 30 V
  • Operating current (door opener): 0.7 A
  • Power consumption (typical): 4.7 W

Operational conditions


  • Operating temperature (T-T): -40 - 60 °C
  • Storage temperature (T-T): -40 - 65 °C
  • Operating relative humidity (H-H): 10 - 100%

Weight & dimensions


  • Width: 124 mm
  • Height: 124 mm
  • Weight: 900 g

Logistics data


  • Harmonized System (HS) code: 85176920
