ARCTIC P8 Max - High-Performance 80 mm PWM Fan
More info
Brand: ARCTIC COOLING
7.84 €
6.48 €
without VAT
Stock available: 22 units.
Get it
on the
September 1
/
September 2
SKU:
105136
PRC:
514473
EAN:
4895213704090
PN:
ACFAN00286A
Description
8 cm black fan intended for your computer case, supplied as a single unit, featuring dual-row ball bearings and five blades for an airflow of 67.96 m³/h. This ARCTIC COOLING model achieves a static pressure of 5.3 mmH2O and spins between 500 and 5000 RPM thanks to its 4-pin connector, compatible with pulse-width modulation (PWM) to adjust speed according to temperature. Its noise level is 0.6 sone and it offers a mean time to failure of 500,000 hours, operating within a range of 0 to 40 °C, with a rack capacity of 2U. Designed for integration into chassis, this fan provides a maximum flow of 40 cfm, ideal for optimising internal cooling without complications.
Specifications
Performance
- Suitable location: Computer case
- Type: Fan
- Fan diameter: 8 cm
- Noise level: 0.6 sone
- Maximum airflow: 40 cfm
- Airflow: 67.96 m³/h
- Pulse-width modulation (PWM) support: Yes
- Fan bearing technology: Double ball bearing
- Quantity per pack: 1 pc(s)
- Fan speed (min): 500 RPM
- Fan speed (max): 5000 RPM
- Fan static pressure: 5.3 mmH2O
- Fan's mean time to failure (MTTF): 500000 h
- Operating temperature (T-T): 0 - 40 °C
Design
- Product colour: Black
- Number of fans: 1 fan(s)
- Number of fan blades: 5
- Fan connector: 4-pin
- Rack capacity: 2U
Power
- Starting voltage: 3.2 V
- Fan voltage: 12 V
- Fan current: 0.19 A
Weight & dimensions
- Fan dimensions (W x D x H): 80 x 80 x 25 mm
- Fan weight: 84 g
- Cable length: 0.4 m
- Package width: 82.5 mm
- Package depth: 82.5 mm
- Package height: 26 mm
- Package weight: 89 g
Packaging content
- Mounting kit: Yes
- Screws included: Yes
Other features
- Country of origin: Hong Kong
