Description
APC Easy 3S, Double-conversion (Online), 10 kVA, 10000 W, Pure sine, 304 V, 477 V
Specifications
Features
- UPS topology: Double-conversion (Online)
- Output power capacity: 10 kVA
- Output power: 10000 W
- Waveform: Pure sine
- Input operation voltage (min): 304 V
- Input operation voltage (max): 477 V
- Input frequency: 45/65 Hz
- Output operation voltage (min): 380 V
- Output operation voltage (max): 415 V
- Output frequency regulation: 50/60 Hz
- Maximum current: 18 A
- Number of input phases: 3
- Number of output phases: 3
- Input power factor: 0.99
- Output voltage Total Harmonic Distortion (THD): 3%
- Noise level: 60 dB
Battery
- Battery technology: Sealed Lead Acid (VRLA)
- Battery voltage: 240 V
- Number of batteries supported: 3
- Typical backup time at full load: 40 min
Design
- Form factor: Tower
- Product colour: White
- International Protection (IP) code: IP20
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -15 - 40 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 999.9 m
- Non-operating altitude: 0 - 15000 m
Certificates
- Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE
Packaging content
- Quick installation guide: Yes
Weight & dimensions
- Width: 380 mm
- Depth: 928 mm
- Height: 1400 mm
- Weight: 112 kg
Packaging data
- Package width: 563 mm
- Package depth: 1014 mm
- Package height: 1640 mm
- Package weight: 145 kg
Logistics data
- Harmonized System (HS) code: 85078000
Other features
- Output voltage: 400 V
