Description
54V, 10 Gigabit, 120-240 V, 60W, 100 x 58.4 x 33.4 mm
Specifications
Network
- Ethernet interface type: 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet
- Ethernet LAN data rates: 10, 100, 1000, 2500, 10000 Mbit/s
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Features
- Product colour: Black
- Wall mountable: Yes
- LED indicators: Power
- Pin assignment & polarity: Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc-)&Pin8(Vdc-); Pin1(Rx+)&Pin2(Rx-); Pin3(Tx+)&Pin6(Tx-)
- Power protection features: Over current, Over voltage, Short circuit
Power
- Power over Ethernet (PoE) voltage: 54 V
- Output power: 60 W
- Input voltage: 100 - 240 V
- Input frequency: 50 - 60 Hz
- Input current: 1.12A @ 120V AC, 0.75A @ 240V AC
- Surge protection voltage: 4 kV
Certificates
- Compliance certificates: CB, CE, Federal Communications Commission (FCC), UL
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
- Width: 100 mm
- Depth: 58.4 mm
- Height: 33.4 mm
- Weight: 198 g
Logistics data
- Warranty period: 1 year(s)
