Description
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1p, IEEE 802.3at
- 10G support: No
- Full duplex: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
Data transmission
- Switching capacity: 48 Gbit/s
- MAC address table: 8000 entries
- Latency (1 Gbps): 4 µs
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet forwarding rate (1 Gbps): 1448000 pps
- Packet buffer memory: 0.192 MB
Security
- Queue scheduling algorithms: Weighted Round Robin (WRR)
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- Housing material: Metal
- LED indicators: Activity, Link, PoE, Power, Speed
- Number of fans: 1 fan(s)
- Electromagnetic compatibility: CE, FCC 15 A, IC A, RCM, VCCI, KC
Performance
- Mean time between failures (MTBF): 1193574 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 3 A
- Power consumption (max): 210 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 16
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 190 W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 95%
- Operating altitude: 0 - 3000 m
- Heat dissipation: 718.2 BTU/h
Weight & dimensions
- Width: 330 mm
- Depth: 206 mm
- Height: 43 mm
- Weight: 2.44 kg
Certificates
- Certification: CB, CE LVD, UL
Logistics data
- Harmonized System (HS) code: 85176990
