Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
- SFP+ module slots quantity: 1
Network
- Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3x, IEEE 802.1p, IEEE 802
- 10G support: No
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- VLAN support: Yes
- Virtual LAN features: MTU VLAN, Port-based VLAN
Data transmission
- Switching capacity: 45 Gbit/s
- Forwarding rate: 33.48 Mpps
- MAC address table: 16000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 10
- Packet buffer memory: 0.64 MB
Security
- DHCP features: DHCP client
- IGMP snooping: Yes
Design
- Form factor: Desktop/Wall-Mounting
- Product colour: Black
- LED indicators: Yes
Performance
- Flash memory: 64 MB
- Firmware upgradeable: Yes
- Mean time between failures (MTBF): 1223587 h
Power
- Power source: AC
- AC input voltage: 100 - 240 V
- Power consumption (max): 5.63 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 19.21 BTU/h
Weight & dimensions
- Width: 158 mm
- Depth: 100.7 mm
- Height: 25.4 mm
- Weight: 520 g
Certificates
- Certification: CE, FCC, RoHS
