Description
Specifications
Design
- LED indicators: Power
Performance
- Internal memory: 128 MB
- Flash memory: 16 MB
Network
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Security
- VLAN support: Yes
- Access point isolation: Yes
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 4
- WAN connection: Ethernet (RJ-45)
Management features
- Quality of Service (QoS) support: Yes
- Reset button: Yes
- Syslog: Yes
Power
- Power consumption (typical): 5 W
- Input voltage: 12 V
- Input current: 1.5 A
Weight & dimensions
- Width: 142 mm
- Depth: 45 mm
- Height: 232 mm
- Weight: 780 g
- Dimensions (WxDxH): 232 x 142 x 45 mm
Packaging data
- Package width: 215 mm
- Package depth: 60 mm
- Package height: 260 mm
- Package weight: 1.2 kg
- Package type: Box
Packaging content
- Cables included: LAN (RJ-45)
- Quick installation guide: Yes
Operational conditions
- Operating temperature (T-T): -20 - 50 °C
- Storage temperature (T-T): -30 - 70 °C
- Operating relative humidity (H-H): 5 - 90%
Technical details
- Package dimensions (WxDxH): 215 x 60 x 260 mm
Certificates
- Certification: EN 55022: 2010+AC:2011 EN 61000-3-2:2014 EN 61000-3-3:2013 EN 55024: 2010+A1:2015\ CE
Logistics data
- Country of origin: China
- Harmonized System (HS) code: 85176990
- Master (outer) case width: 230 mm
- Master (outer) case length: 262 mm
- Master (outer) case height: 620 mm
- Master (outer) case gross weight: 13 kg
- Products per master (outer) case: 10 pc(s)
