SKU:
77081
PRC:
126806
EAN:
65030864763
PN:
ICUSB23216FD
Description
Specifications
Ports & interfaces
- Host interface: USB 2.0 Type-B
- Hub interfaces: Serial
- Ports quantity: 16
- RS-232 ports: 16
- Terminal block port: Yes
- DC-in jack: Yes
Features
- Data transfer rate: 480 Mbit/s
- Product colour: Black
- Housing material: Steel
- LED indicators: Yes
Power
- Power consumption (max): 36 W
- Input voltage: 100 - 240 V
- Input current: 1.5 A
- Output voltage: 12 V
- Output current: 3 A
- Power plug type: Type N
System requirements
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
- Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
- Linux operating systems supported: Yes
- Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 20
- Other operating systems supported: Windows XP Embedded
Weight & dimensions
- Width: 120 mm
- Depth: 430 mm
- Height: 45 mm
- Weight: 1.55 kg
Packaging data
- Package width: 215 mm
- Package depth: 451 mm
- Package height: 61 mm
- Package weight: 2.31 kg
Packaging content
- AC adapter included: Yes
- Included power plug types: AU, EU, NA, UK
- Cables included: USB
- Quick installation guide: Yes
Operational conditions
- Operating temperature (T-T): -40 - 85 °C
- Storage temperature (T-T): -65 - 150 °C
- Operating relative humidity (H-H): 20 - 80%
Performance
- Data bits: 7, 8
- Stop bits: 1, 2
- Parity bit: Even, Mark, No, Odd, Space
- FIFO (First In, First Out): 256 B
- Baud rate: 921.6 Kbit/s
- Mean time between failures (MTBF): 49337 h
Sustainability
- Sustainability compliance: Yes
Logistics data
- Master (outer) case width: 341 mm
- Master (outer) case length: 477 mm
- Master (outer) case height: 238 mm
- Products per master (outer) case: 5 pc(s)
- Harmonized System (HS) code: 84719000
Technical details
- Compliance certificates: CE, RoHS
Other features
- Rack mounting: Yes
- Chipset: FTDI - FT232RL
