Description
The MSI PRO H610M-G DDR4 motherboard, in micro ATX format, is designed for building systems with Intel Core i9 processors on the LGA 1700 socket. It features two DIMM slots that support non-ECC DDR4-SDRAM memory in dual channel, up to a maximum of 64 GB, with speeds of 2133, 2666, 2933 and 3200 MHz. For storage it has an M.2 interface and four SATA III connectors, so you can combine fast SSDs with additional drives. It has two internal USB 2.0 connectors and a front panel audio connector to get the system ready. Its dimensions are 211 x 65 x 244 mm (width x height x depth) and its weight is 764 g, values worth taking into account when planning the case and the build. The integrated graphics works with DirectX 12.0.
Specifications
Processor
- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i9
- Supported processor sockets: LGA 1700
Memory
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 2
- Memory slots type: DIMM
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
- Supported memory clock speeds: 2133, 2666, 2933, 3200 MHz
- Maximum internal memory: 64 GB
Storage controllers
- Supported storage drive types: SSD
- Supported storage drive interfaces: M.2, SATA III
Graphics
- Parallel processing technology support: Not supported
- DirectX version: 12.0
Internal I/O
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- TPM connector: Yes
- 12V power connector: Yes
Rear panel I/O ports
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- VGA (D-Sub) ports quantity: 1
- HDMI ports quantity: 1
- DisplayPorts quantity: 1
Network
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Features
- Motherboard chipset: Intel H610
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
- Component for: PC
- Motherboard form factor: micro ATX
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 10, Windows 11
BIOS
- BIOS type: UEFI AMI
Logistics data
- Harmonized System (HS) code: 84733020
Weight & dimensions
- Width: 211 mm
- Depth: 244 mm
- Height: 65 mm
Packaging content
- Cables included: SATA
- Drivers included: Yes
Other features
- Weight: 764 g
