Description
Specifications
Power
- Total power: 450 W
- Peak power: 500 W
- AC input voltage: 220 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 4 A
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 100 W
- Combined power (+12V): 444 W
- Combined power (+5V): 100 W
- Combined power (-12V): 3 W
- Combined power (+5Vsb): 12.5 W
- Max output current (+3.3V): 15 A
- Max output current (+12V): 37 A
- Max output current (+5V): 15 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 2.5 A
- Hold time: 16 ms
- Efficiency: 87%
- Power protection features: Over current, Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Motherboard power cable length: 50 cm
- Number of SATA power connectors: 4
- SATA power cable length: 500, 600, 700, 800 mm
- Peripheral (Molex) power connectors (4-pin): 2
- Peripheral (Molex) power cable length: 500, 600 mm
- PCI Express power connectors (6+2 pin): 2
- PCI Express power cable length: 60 cm
- CPU power connector (4+4 pin): Yes
- CPU power cable length: 60 cm
- ATX power connector (20+4 pin): Yes
- PCI Express connector: Yes
- Cabling type: Semi-Modular
Performance
- 80 PLUS certification: 80 PLUS Bronze
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 2.31
- Mean time between failures (MTBF): 100000 h
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 12 cm
- Number of fans: 1 fan(s)
- Fan location: Top
- On/off switch: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
Certificates
- Compliance certificates: CE, RoHS
- Certification: CB
Safety regulation & standards
- Safety: ErP 2013 Lot 6, ErP 2014 Lot, EU 617/2013
Weight & dimensions
- Width: 150 mm
- Depth: 160 mm
- Height: 86 mm
- Weight: 1.62 kg
Packaging data
- Package width: 233 mm
- Package depth: 196 mm
- Package height: 95 mm
- Package weight: 1.72 kg
- Package type: Box
