Description
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- 2.5G Ethernet (copper) ports quantity: 5
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Cable types supported: Cat3, Cat4, Cat5, Cat5e
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
Data transmission
- Switching capacity: 25 Gbit/s
- Forwarding rate: 18.6 Mpps
- MAC address table: 4000 entries
- Store-and-forward: Yes
Security
- IGMP snooping: Yes
Design
- Rack mounting: No
- Product colour: Black
- Housing material: Steel
- LED indicators: Yes
Performance
- Fanless: Yes
Power
- Power source: DC/PoE
- Power supply included: Yes
- Number of power supply units: 1
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- Input current: 2.43 A
- Input voltage: 53.5 V
- Power consumption (max): 143.37 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet 4PPoE (PoE++) ports quantity: 4
- Power over Ethernet (PoE) power per port: 60 W
- Total Power over Ethernet (PoE) budget: 123 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 488.89 BTU/h
Weight & dimensions
- Width: 209 mm
- Depth: 126 mm
- Height: 26 mm
Packaging content
- Cables included: AC
- User guide: Yes
Packaging data
- Package type: Box
Certificates
- Certification: CE, FCC, RoHS
