Description
Specifications
Network
- Maximum data transfer rate: 1000 Mbit/s
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- Store-and-forward: Yes
- Duplex system: Full, Half
Performance
- Maximum transfer distance: 20000 m
- Wavelength: 1310 nm
- Fiber mode structure: Single-mode
Features
- Internal: No
- LED indicators: Activity, Link, Power
- Product colour: Grey
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
- Fiber ports quantity: 1
- Fiber optic connector: SC
Power
- Input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 1.6 A
- Output voltage: 48 V
- Output current: 2 A
- Power consumption (max): 40 W
- Power over Ethernet (PoE): Yes
- Total Power over Ethernet (PoE) budget: 30 W
- External power adapter: Yes
Weight & dimensions
- Width: 70 mm
- Depth: 94 mm
- Height: 26 mm
- Weight: 200 g
Operational conditions
- Operating temperature (T-T): 10 - 60 °C
- Operating relative humidity (H-H): 5 - 90%
Packaging content
- AC adapter included: Yes
- User guide: Yes
Packaging data
- Package width: 230 mm
- Package depth: 150 mm
- Package height: 60 mm
- Package weight: 650 g
Logistics data
- Country of origin: China
- Master (outer) cases per pallet (air): 23 pc(s)
- Pallet gross length: 80 cm
- Pallet gross width: 120 cm
- Pallet height (air): 176.9 cm
- Master (outer) case width: 480 mm
- Master (outer) case length: 305 mm
- Master (outer) case height: 325 mm
- Master (outer) case gross weight: 13.8 kg
- Products per master (outer) case: 20 pc(s)
